Dixie Narco 55 Series - Page 71

ELECTRICAL DIAGRAMS & SCHEMATICS
70
SERVICE DOOR (BACK)
INDEX
NUMBER PART NUMBER PART DESCRIPTION
1 F557 Spacer, 10-32 .31 OD .6252L – 3 Point Lock
2 800,503,31x.x1 Latch Bar – 3 Point Lock
801,305,58x.x1 Bottom Latch – 3 Point Lock
3 900,201,87x.x1 Phillips Trusshead Screw #10-32x3/8
4 F240-3 Latch Spacer – 3 Point Lock
5 900,701,10x.x1 Washer, Flat .191 ID .50 OD
6 900,701,22x.x1 Washer, Flat .260 ID x .687 OD
7 900,202,03x.x1 Screw, Shoulder 10-32x1/4
8 801,518,05x.x1 Latch, Pawl – 3 Point Lock
9 627,050,04x.x3 Latch, Rod – 3 Point Lock
10 801,810,07x.x1 Protective Strip, Plastic (2 piece)
11 D588 Keypad Cable Clamp
D114 Keypad Cable Clamp Kit
12 803,853,26x.x1 Service Menu Label DN 5500 / 5400 / 2145
13 W396 Lanyard, Service Door (prior to DN2145)
14 801,806,58x.x1 Hopper and Coin Chute (041-8019BX and higher)
15 801,806,59x.x1 Coin Chute Front (041-8019BX and higher)
