ELECTRICAL DIAGRAMS & SCHEMATICS
72
TALL GATE TRAY DETAIL
NUMBER
PART NUMBER
PART DESCRIPTION
1 622,071,10x.x3
Tray Assembly, 9 Column ALL DN5592/5593/5591/5594 prior to 0001-
8107; ALL DN2145, All DN5493
622,070,70x.x3 Top Tray Assy., 9 Column Tall Gate, Export DN2145 prior to 0001-8072
622,053,0x.x3 Tray Assy., 8 Column DN5483
627,070,80x.x3 Tray Assy., 9 Column Domestic DN5591/5594 (0001-8107 & higher)
635,070,00x.x3 Tray Assy. 6 Column DN35##
2 622,052,60x.x4 Solenoid, 24 Volt w/ Plunger and Spring Assembly Kit
3 801,519,29x.x1 Plunger and Spring
4 804,300,16x.x1 Body
5 626,070,09x.x3 Chassis Tray, Tall Gate 9 Column DN55##
635,070,01x.x3 Chassis Tray, Tall Gate 6 Column DN35##
622,070,08x.x3 Chassis Tray, Tall Gate 8 Column DN55##
6 801,903,83x.x1 Gate Assy., w/ Kicker (8054 and up)
7 Spacers (also refer to TB 514)
7A 801,813,63x.x1 Spacer, Tall Gate 3/16” (.155)
7B 801,813,62x.x1 Spacer, Tall Gate, 3/8” (.340)
7C 801,812,02x.x1 Spacer, Tall Gate (150 / 70)
7D 801,812,69x.x1 Spacer “A” (210 / 70)
7E 801,812,98x.x1 Spacer (340 / 210)
7F 801,812,81x.x1 Spacer “B” (90 / 70)
7G 801,817,39x.x1 Spacer (340 / 210 / 777) was 801,813,53x.x1
7H 801,813,71x.x1 Spacer (340 / 590)
7I 801,813,78x.x1 Spacer (155 / 530)
7J 801,817,38x.x1 Spacer (155 / 405) was 801,813,76x.x1
7K 801,815,36x.x1 Spacer Rail Assembly (metal) was 622,053,10x.x3
7L 801,811,09x.x1 Product Pusher Rail
8 W789 Cotter Pin
9 801,903,81x.x1 Slide with Product Pusher Assy (8054 and up) (Tall Gate Only)
10 801,401,98x.x1 Tray Wire, Formed Domestic 9 Column DN55##
801,401,96x.x1 Tray Wire, Formed Domestic 8 Column
801,401,89x.x1 Tray Wire, Formed Export
801,402,21x.x1 Tray, Wire Formed Domestic DN35##
11 622,070,04x.x3 Bracket, Side Tray
12 W834 Plastic Tray Cap
13 W398 Washer, Retainer
14 801,813,06x.x1 Washer, Solenoid Retainer
15A 801,903,63x.x1 Stabilizer “C” Tray (Short)
15B 801,903,64x.x1 Stabilizer “D” Tray (Long)
15C 801,903,85x.x1 Stabilizer, Special
16 D334 Screw, Hex Washer 4-24x3/4
17 804,913,74x.x1 Tray Harness DN55##
804,920,34x.x1 Tray Harness DN35##
18 622,010,00x.x4 Kit 6 to 5 Tray Conversion 3 New Trays and Bracket
19 622,010,10x.x4 Kit 6 to 5 Tray Conversion Kit 5 New Trays and Brackets
To Next Page
