ELECTRICAL DIAGRAMS & SCHEMATICS
74
DOMESTIC AC DISTRIBUTION BOX, 110 VAC
NUMBER
PART NUMBER
PART DESCRIPTION
1 622,052,70x.x4
Domestic AC Box Kit – includes AC Box, Main Power Harness, and MDB
Interior Power Harness
2A 622,060,10x.x3 AC Distribution Box, 110 V / 60 Hz
2B 635,060,30x.x3 Assy. AC Distribution T8 Electronic GFV
3A 804,913,75x.x1 MDB Interior Power Harness
3B 804,920,55x.x1 MDB Interior Power Harness T8/Electronic GFV
3C 804,914,06x.x1 Micromech Interior Power Harness
3D 804,913,77x.x1 Main Power Harness (Williston AC Distribution Box)
3E F194 Main Power Harness 125V, 20 A (prior to 0001-8000)
4A 802,800,47x.x1 Thermostat, Cold Control (prior to 0016-8095)
4B 802,800,60x.x1 Defrost Thermostat GE (for dual control) (0016-8095 and higher)
4C 802,800,66x.x1 Cold Control GE (for dual control) (0016-8095 and higher)
5 W641 Varistor, 25 Amp, 650V
6 804,915,54x.x1 Transformer, 120V / 24V, 60 Hz, 8A Domestic
7 803,853,21x.x1 2 Amp Fuse / 10 Amp Fuse Label
8 803,853,22x.x1
Label, Electrical Box, “WARNING – Disconnect Main Power Cord Before
9 W659 Fuse, 10 Amp, 32V SloBlo
10 804,920,02x.x1 Fuse Holder, Panel Mounted, Quick Disconnect
11 W662 Outlet, 15 Amp, Grounded
12 W658 Fuse, 2 Amp, 250V, SloBlo
13 804,915,15x.x1 Switch, Rocker, Panel Mounted (prior to 0001-8000) Domestic
14 804,913,62x.x1 Power Inlet Plug
15A 804,915,05x.x1 Thermostat Harness (069-8018 to 0016-8095)
15B 804,914,39x.x1 Dual Thermostat Harness (0016-8095 and higher)
16A 622,060,13x.x3 Dual Temperature Control Bracket (0016-8095 and higher)
16B 491,070,08x.x3 Temperature Control Bracket (086-8018 to 0016-8095)
16C 491,070,08x.x3 Marked Temperature Control Plate
17 622,060,08x.x3
AC Distribution Box Hole Cover for Temperature Control Relocation (prior to
086-8018)
18 803,847,08x.x1 Temperature Control Label
19 800,902,63x.x1 Temperature Control Clip
