ELECTRICAL DIAGRAMS & SCHEMATICS
76
EXPORT AC DISTRIBUTION BOX, 220 VAC
NUMBER
PART NUMBER
PART DESCRIPTION
1 622,061,40x.x3 AC Distribution Box, Export CE / GS
2A 804,913,75x.x1 MDB Interior Power Harness
2B 804,914,06x.x1 MicroMech Interior Power Harness
2C F535 Plug, 15 Amp, 240 V (Power In) – 2 Pole 3 Wire (Main Power Plug)
2D 804,914,94x.x1 AC Power-In Export Harness
3A 802,800,75x.x1 Thermostat, Cold Control (prior to 0016-8095)
3B 802,800,70x.x1 Export Defrost Thermostat GE (for dual control) (0016-8095 and higher)
3C 802,800,76x.x1 Export Cold Control GE (for dual control) (0016-8095 and higher)
4 W641 Varistor, 25 Amp, 650 V
5 804,914,18x.x1 Transformer, 230 V / 24 V, 50 Hz
6 803,853,55x.x1 Label, Fuse 10 Amp, 2 Amp and Lamp 250 V
7A 803,853,22x.x1
Label, AC Box, “WARNING – Disconnect Main Power Cord Before
Servicing” (English)
7B 803,858,69x.x1 Label AC Box (German)
8 804,914,25x.x1 Fuse, 10 Amp, 250 V, 5x20 mm Sloblo
9 804,914,88x.x1 Fuse Holder, Export DN 2145 5x20 mm
10 F443 Socket, 13 Amp, 250V British
11A 804,914,24x.x1 Fuse, 2 Amp, 250 V 5x20 mm Sloblo
11B 804,914,23x.x1 Fuse, 1 Amp, 250 V 5x20 mm Sloblo
11C 804,919,56x.x1 Fuse, 1.25 Amp, 250 V, 5x20 mm Sloblo
12 804,913,62x.x1 Power Inlet Plug
13A 804,915,05x.x1 Thermostat Harness (068-8018 to 0016-8095)
13B 804,914,39x.x1 Dual Thermostat Harness (0016-8095 and higher)
14A 622,060,13x.x3 Dual Temp Control Bracket (0016-8095 and higher)
14B 491,070,08x.x3 Temperature Control Bracket (086-8018 to 0016-8095)
14C 491,070,08x.x3 Marked Temperature Control Plate
15 622,060,08x.x3
AC Distribution Box Hole Cover for Temperature Control Relocation (prior to
086-8018)
16 803,847,08x.x1 Temperature Control Label
17 800,902,63x.x1 Temperature Control Clip
18 804,101,12x.x1 Green Rocker Switch
19A 804,914,17x.x1 Main Power Cord 220 V Export (Europe)
19B 804,918,72x.x1 Power Cord United Kingdom 78”
19C 804,914,87x.x1 Main Power Cord 220 V Australia
19D 804,917,77x.x1 Power Cord Denmark
19E 804,917,78x.x1 Power Cord Israel
19F 804,919,49x.x1 Power Cord South Africa
20 804,916,93x.x1 3 Position Rotary Switch
