COLA MARKETING MACHINE SERVICE MANUAL
PULL OUT HANDLE & COIN INSERT
ITEM # DESCRIPTION PART NUMBER
1A Assy. T-handle
801,518,20x.x1
1B T-Handle Flange
801,518,18x.x1
1C T-Handle Only
801,518,14x.x1
1D T-Handle Stud
801,518,17x.x1
2 Coin Chute Assy.
624,052,60x.x3
3A Coin Return Assy.
624,052,50x.x3
3B Push Button Coin Return
801,807,25x.x1
3C Coin Return Button Bracket
624,050,23x.x3
3D Bushing
.500x.625 801,903,13x.x1
3E Coin Return Rocker
#6 (serial break not available at print) 805,700,61x.x1
#8 (first 10,000 venders - s/n 0001-6501BW to ####-####) 805,700,56x.x1
3F Roller Pin
900,502,19x.x1
3G Roller Pin Retainer
900,900,90x.x1
3H Coin Return Cable Assy.
#6 Cable (serial break not available at print) 801,305,15x.x1
#8 Cable (first 10,000 venders - s/n 0001-6501BW to ####-####) 801,305,17x.x1
3I Coin Return Changer Bracket
624,050,21x.x3
3J Coin Return Changer Rocker
624,050,45x.x3
3K Coin Return Spring
901,701,07x.x1
3L Wing Nut
6-32 (serial break not available at print) 800,801,14x.x1
8-32 (first 10,000 venders - s/n 0001-6501BW to ####-####) 800,801,15x.x1
4 Coin Chute Bracket
805,701,01x.x1
5A Display Lens
801,810,67x.x1
5B Display Lens Gasket
802,001,28x.x1
6 Coin Insert Label
S3D 803,853,85x.x1
SIID 803,853,83x.x1
7 Coin Chute Can Diverter
805,701,11x.x1
