Dixie Narco DNCB 348 - Inner Door

COCA
-
COLA MARKETING MACHINE SERVICE MANUAL
D
IXIE
-
NARCO, INC.
INNER DOOR
ITEM # DESCRIPTION PART NUMBER
1 Inner Door Assy.
79" Wide 624,051,00x.x3
72" Wide 624,051,10x.x3
72" Narrow 624,051,20x.x3
2 Inner Door Gasket
79" Wide 801,804,07x.x1
72" Wide 801,804,06x.x1
72" Narrow 801,804,03x.x1
3 Knob
901,501,70x.x1
4A Discharge Frame Assy.
801,809,16x.x1
4B Discharge Frame Retainer
801,809,15x.x1
5A Inner Door Top Hinge Assy.
169,053,00x.x3
5B Inner Door Bottom Hinge Assy.
169,051,10x.x3
5C Plastic Bearing
901,803,71x.x1
6A Bushing, Inner Door
801,806,42x.x1
6B Bushing Retainer, Inner Door
801,806,43x.x1
A4 Screw, Phil Pan w/out Washer #8-18x½ 900,301,50x.x1
A15 Screw, Machine Truss #10-32x½ 900,201,14x.x1
A16 Screw, Phil Pan Sems #8-18x½ 900,301,65x.x1
A34 Screw, Phil Pan #6-20x
3
/
8
800,303,22x.x1
B1 Keps Nut #10-32 900,800,65x.x1
E3 Carriage Bolt, ¼-20x1¼ 900,201,23x.x1
