Dixie Narco DNCB 348 - Lighting

COCA
-
COLA MARKETING MACHINE SERVICE MANUAL
D
IXIE
-
NARCO, INC.
LIGHTING
ITEM # DESCRIPTION PART NUMBER
1 Fluorescent Bulb
1A F64T12/D H/O (72") 804,700,37x.x1
F72T12/D H/O (79") 804,700,36x.x1
1B F42T12D H/O (72") 804,700,64x.x1
F48T H/O (79") 804,700,39x.x1
1C 48" T8 Metric Philips TLD 36W/840 NG (export) 804,700,66x.x1
60" T8 Metric Philips TLD 58W/840 NG (export) 804,700,67x.x1
72" T8 Metric Philips TLD 70W/840 NG (export) 804,700,68x.x1
2 Door Bracket, Lamp Socket
110V (.045 x 2.684 x 2.985) - 4 per 624,050,39x.x3
220 / 50 (.045 x 3.043 x 2.289) - 3 per 624,000,04x.x3
220 / 50 79" Bulkhead Socket Bracket (.045 x 2.061 x 3.491) - 1 per 624,050,92x.x3
3 Lampholder, Top
H/O 523 804,901,99x.x1
4 Lampholder, Bottom
H/O 524 804,902,00x.x1
T8 (220 / 50) - 4 per (Leviton 13351-UN) 804,917,16x.x1
5 Light Harness, Plug In
H/O 804,916,02x.x1
220 / 50 Light Harness 804,917,14x.x1
6 Ballast
High Output 110V/60Hz (domestic) 804,400,38x.x1
High Output 220 / 240V, 50 / 60 Hz (export) 804,400,55x.x1
7 Jumper, H/O Lamp Fixture 22"
Bottom 110V/60Hz (domestic) 22" 804,913,93x.x1
220 / 50 Lamp Fixture 24" 804,916,06x.x1
8 Boot, Lamp
902,001,21x.x1
9 Lamp Socket Shield
624,050,83x.x3
10 220 V (International) Ballast Jumper
804,917,15x.x1
A1 Screw, Phil Pan Swage Form #6-32x
3
/
8
900,301,70x.x1
