COLA MARKETING MACHINE SERVICE MANUAL
CABINET INTERIOR
ITEM
DESCRIPTION DNCB 600E DNCB 501E DNCB 276E
79" Wide 72" Wide 72" Narrow
1 Foam Cabinet Assy.
All Styles 624,000,50x.x3 624,000,30x.x2 624,000,10x.x3
2A Stack Assy.
Single Price - Cans 610,070,30x.x3 609,071,00x.x3 NA
SIID - Cans 610,070,50x.x3 609,071,20x.x3 NA
Single Price - Bottles 610,070,70x.x3 609,071,40x.x3 NA
SIID - Bottles 610,070,80x.x3 609,071,50x.x3 NA
Stack Assy. Single Price - No Shimming NA NA 615,070,40x.x3
Stack Assy. SIID - No Shimming NA NA 615,070,00x.x3
Single Price -330 ml Can 4 deep 610,071,60x.x3 609,074,30x.x3 609,074,80x.x3
SIID -330 ml Can 4 deep 610,071,70x.x3 609,074,40x.x3 609,074,90x.x3
2B Stack Sub Assy.
All Styles 610,070,40x.x3 609,071,10x.x3 615,070,10x.x3
330 ml Can 4 Deep Single Price 610,071,80x.x3 609,074,50x.x3 609,075,00x.x3
3A Rear Spacer Assy. Wide Column
All Styles 497,073,10x.x3 498,071,30x.x3 NA
3B Rear Spacer Assy. Narrow Column
All Styles 497,073,20x.x3 498,071,40x.x3 498,071,40x.x3
3C Latch Spring
Wide 901,700,88x.x1 901,700,88x.x1 NA
Narrow 901,700,86x.x1 901,700,86x.x1 901,700,86x.x1
4 Protective Plate Left Side
All Styles 594,020,17x.x3 594,020,14x.x3 594,020,14x.x3
5A Gate, Wire
All Styles 801,401,73x.x1 801,401,72x.x1 801,401,76x.x1
5B Wire Gate Latch Lock & Guide
All Styles 801,401,77x.x1 801,401,77x.x1 801,401,77x.x1
5C Wire Gate Bracket Top
All Styles 609,070,36x.x3 609,070,36x.x3 609,070,36x.x3
5D Gate Label - Caution "E"
All Styles 803,855,82x.x1 803,855,82x.x1 803,855,82x.x1
5E Clamp, Nylon Cable 1/2"
All Styles 900,901,80x.x1 900,901,80x.x1 900,901,80x.x1
6A Mullion
All Styles 801,810,56x.x1 801,810,56x.x1 801,810,85x.x1
6B Mullion Cover
All Styles 801,303,83x.x1 801,303,83x.x1 801,303,83x.x1
7A Breaker Strip Right
All Styles 491,020,15x.x3 492,020,04x.x3 492,020,04x.x3
7B Breaker Strip Left
All Styles 491,020,16x.x3 492,020,05x.x3 492,020,05x.x3
7C Breaker Strip Top
All Styles 491,020,17x.x3 491,020,17x.x3 493,020,06x.x3
8 Leveling Leg 5/8"-11x2 1/16"
All Styles 900,502,49x.x1 900,502,49x.x1 900,502,49x.x1
9 Mounting Bracket, Rear
All Styles 609,070,24x.x3 609,070,24x.x3 609,070,24x.x3
10 Cabinet Front Stiffener Plate
All Styles 594,021,10x.x3 594,021,10x.x3 596,020,20x.x3
