Dixie Narco DNCB 348 - Refrigeration System Components; Complete Refrigeration Systems; Compressor Components; Condenser Components

COCA
-
COLA MARKETING MACHINE SERVICE MANUAL
D
IXIE
-
NARCO, INC.
REFRIGERATION SYSTEM
ITEM DESCRIPTION DNCB 600E DNCB 501E DNCB 276E
79" Wide 72" Wide 72" Narrow
1 Complete Refrigeration System
All Styles Domestic (1203C-E) 609,040,90x.x3 609,040,90x.x3 609,040,90x.x3
1/3 HP 220-240/50 "E" (1223-E IEC) 609,041,10x.x3 609,041,10x.x3 609,041,10x.x3
1/3 HP 220-240/50 "E" (1223-E AUS) 609,041,30x.x3 609,041,30x.x3 609,041,30x.x3
1/3 HP 220-240/50 "E" (1223-E GEN) 609,041,50x.x3 609,041,50x.x3 609,041,50x.x3
2A Compressor
FFI12HBX 115/60 1/3 HP 802,501,74x.x1 802,501,74x.x1 802,501,74x.x1
FFI12HBK 220/50 1/3 HP 802,502,17x.x1 802,502,17x.x1 802,502,17x.x1
2B Compressor Lead Harness
115/60 (1203CB-E) 904,900,61x.x1 904,900,61x.x1 904,900,61x.x1
Europe 804,905,32x.x1 804,905,32x.x1 804,905,32x.x1
IECA 804,904,49x.x1 804,904,49x.x1 804,904,49x.x1
220/50 904,900,61x.x1 904,900,61x.x1 904,900,61x.x1
2C Compressor Mounting Grommet
All Styles 902,000,57x.x1 902,000,57x.x1 902,000,57x.x1
2D Compressor Mounting Clip
All Styles 900,901,88x.x1 900,901,88x.x1 900,901,88x.x1
2E Compressor Grommet Plug, Plastic
All Styles 901,803,91x.x1 901,803,91x.x1 901,803,91x.x1
3A Condenser Base Plate
All Styles 491,040,25x.x3 491,040,25x.x3 491,040,25x.x3
3B Condenser Fan Motor Assy.
115/60 491,040,20x.x3 491,040,20x.x3 491,040,20x.x3
220/50 491,140,30x.x3 491,140,30x.x3 491,140,30x.x3
3C Condenser Fan Motor And Bracket (“A” Frame)
115/60 804,500,67x.x1 804,500,67x.x1 804,500,67x.x1
220/50 804,500,70x.x1 804,500,70x.x1 804,500,70x.x1
3D Condenser Fan Blade
All Styles FY870CW25S 800,103,37x.x2 800,103,37x.x2 800,103,37x.x2
4A Drain Pan Assy. w/ Fiberglass Soakers
All Styles 491,000,10x.x3 491,000,10x.x3 491,000,10x.x3
4B Drain Pan, Plastic w/ Fingers
All Styles 801,804,24x.x1 801,804,24x.x1 801,804,24x.x1
4C Soakers, Fiberglass (14 required)
All Styles 905,800,69x.x1 905,800,69x.x1 905,800,69x.x1
4D Drain Pan Clamp
All Styles 594,000,06x.x3 594,000,06x.x3 594,000,06x.x3
5 Rear Condensate Plate
All Styles 801,903,52x.x1 801,903,52x.x1 801,903,52x.x1
6A Drain Tube
All Styles 801,806,05x.x1 801,806,05x.x1 801,806,05x.x1
6B Drain Tube Nut
All Styles 900,301,79x.x1 900,301,79x.x1 900,301,79x.x1
7A Drain Hose
All Styles 901,900,50x.x1 901,900,50x.x1 901,900,50x.x1
7B Drain Hose Clamp
All Styles 900,901,03x.x1 900,901,03x.x1 900,901,03x.x1
