TWO-BAR LINKAGE / NUT RETAINER HOUSING
ITEM DESCRIPTION DNCB 600E DNCB 501E DNCB 276E
79" Wide 72" Wide 72" Narrow
1 Linkage and Drive Arm Assy.
All Styles NA NA NA
2A Groove Pin, 1/8x1 3/16 (30mm) - T2
All Styles 900,901,94x.x1 900,901,94x.x1 NA
2B Drive Arm (Zinc)
All Styles 801,200,95x.x1 801,200,95x.x1 NA
3 Linkage Arm (Zinc)
All Styles 801,201,59x.x1 801,201,59x.x1 NA
4A Nyliner, Top
All Styles 901,803,16x.x1 901,803,16x.x1 NA
4B Nyliner, Bottom
All Styles 901,804,77x.x1 901,804,77x.x1 NA
5A Assy., Nut Retainer Housing "E" - 1 point lock
Coke 432,052,50x.x4 432,052,50x.x4 432,052,50x.x4
5B Traditional Nut Retainer Housing - 1 point lock
Coke 432,050,73x.x3 432,050,73x.x3 432,050,73x.x3
5C Cage Nut Traditional - 1 point lock
Coke 801,803,85x.x1 801,803,85x.x1 801,803,85x.x1
5D Square Nut, 1/2-13 N.C. - 1 point lock
All Styles Standard 900,800,57x.x1 900,800,57x.x1 900,800,57x.x1
All Styles High Security 900,801,06x.x1 900,801,06x.x1 900,801,06x.x1
A2 Screw, Phil Pan Swage Form #8-32x1/2" 900,301,64x.x1
A5 Screw, Phil Pan Swage Form #8-32x1/4" 900,301,97x.x1
A11 Screw, Phil Pan Sems #8-32x1/4" 900,301,97x.x1
A17 Screw, Type F, 1/4-20x5/8 900,302,01x.x1
C1 Flat Washer B, Delrin .040 thick 3/8"IDx5/8"OD 900,700,60x.x1
