Dixie Narco DNCB 348 - Hinges and Roller Assembly Components; Main Door Roller Components; Top Hinge Assembly Components; Bottom Hinge Assembly Components

COCA
-
COLA MARKETING MACHINE SERVICE MANUAL
D
IXIE
-
NARCO, INC.
HINGES AND ROLLER ASSY.
ITEM DESCRIPTION DNCB 600E DNCB 501E
79" Wide 72" Wide
1A Roller, Main Door
All Styles 901,806,20x.x1 901,806,20x.x1
1B Roller Pin
All Styles 900,502,19x.x1 900,502,19x.x1
2A Assy., Top Hinge (drop in pin) E-Models All Styles
624,052,90x.x3 624,052,90x.x3
2B Top Hinge (drop in pin) E-Models All Styles
801,305,14x.x1 801,305,14x.x1
2C Top Hinge Spacer
All Styles 169,000,15x.x3 169,000,15x.x3
2D Hinge Bearing
All Styles 805,300,42x.x1 805,300,42x.x1
3A Bottom Hinge Sleeve
All Styles 900,502,64x.x1 900,502,64x.x1
3B Bottom Hinge Pin
900,502,70x.x1 900,502,70x.x1
3C Bottom Hinge
801,305,13x.x1 801,305,13x.x1
A9 Screw, Phil Pan Swage Form #8-32x3/8" 900,301,56x.x1
A15 Screw, Machine Truss #10-32x1/2" 900,201,14x.x1
A17 Screw, Self Tapping 1/4-20x5/8" 900,302,01x.x1
B2 Keps Nut, 1/4-20 900,800,67x.x1
B4 Keps Nut, Top Door Hinge 3/8-16 900,800,69x.x1
B10 Hex Nut, 5/16-28 Center w/Flange (top hinge - drop in) 900,801,02x.x1
C2 Flat Washer Door Hinge 901,303,77x.x1
C10 Washer, Flat 18 Gauge 900,700,83x.x1
C11 Flat Washer, 14 Gauge 5/16"-3/8"x7/8" 900,700,08x.x1
E2 Carriage Bolt, 1/4-20x1 900,201,17x.x1
E6 Carriage Bolt 1/4-20x3/4" 900,201,56x.x1
E8 Carriage Bolt, 1/4-20x1 1/4 (top hinge - drop in) 900,201,85x.x1
E9 Carriage Bolt, 1/4-20x5/8" 800,303,19x.x1
H5 Retainer, Roller Pin 900,900,90x.x1
