Dixie Narco DNCB 348 - Electrical and Control Components

COCA
-
COLA MARKETING MACHINE SERVICE MANUAL
D
IXIE
-
NARCO, INC.
ITEM DESCRIPTION DNCB 600E DNCB 501E DNCB 276E
79" Wide 72" Wide 72" Narrow
8 Main Wiring Harness
United States & Mexico 804,902,22x.x1 804,902,22x.x1 804,902,22x.x1
9 Fan Housing Assy.
Double 609,044,00x.x3 609,044,00x.x3 NA
Narrow NA NA 493,040,10x.x3
10A Temperature Control
All Styles 802,800,50x.x1 802,800,50x.x1 802,800,54x.x1
10B Bracket, Temperature Control Extension (.045x5.125x6.671)
624,000,01x.x3 624,000,01x.x3 624,000,01x.x3
11 Condenser Fan Shroud
All Styles 491,040,11x.x3 491,040,11x.x3 491,040,11x.x3
12 Relay (110V / 60 Hz)
Domestic Models Embraco 1.351.605 802,502,13x.x1 802,502,13x.x1 802,502,13x.x1
13 Overload / (110V / 60 Hz)
Domestic Models TIMRT22AFZ-5598 (FOR 1/3 HP) 802,502,10x.x1 802,502,10x.x1 802,502,10x.x1
14 Dryer
All Styles .054 Outlet 4AXH7 802,401,29x.x1 802,401,29x.x1 802,401,29x.x1
15 Condenser
All Styles "B" 1/3 HP 802,600,55x.x1 802,600,55x.x1 802,600,55x.x1
16 Evaporator (short)
CW01655 (1/3 HP) 802,600,37x.x1 802,600,37x.x1 802,600,37x.x1
17 Accumulator
1/3 HP 802,400,46x.x1 802,400,46x.x1 802,400,46x.x1
18A Capacitor, Start
Domestic, 233-280MFD / 115V 60 Hz (FOR 1/3 HP) 802,501,21x.x1 802,501,21x.x1 802,501,21x.x1
18B Capacitor, End Cap Bottom Hole
Domestic 802,501,18x.x1 802,501,18x.x1 802,501,18x.x1
18C Capacitor Assembling Bracket
Domestic 802,501,87x.x1 802,501,87x.x1 802,501,87x.x1
19 Cover, Embraco
1.355.504 Short (Domestic) - 1/3 HP 802,501,86x.x1 802,501,86x.x1 NA
20 Top Evaporator Cover
609,050,06x.x3 609,050,06x.x3 615,050,14x.x3
A9 Screw, Phil Pan 8-32x3/8 900,301,56x.x1
A16 Screw, Phil Pan Sems w/ Washer #8-18x1/2" 900,301,65x.x1
A18 Screw, Hex Head 8-36x3/8" 900,301,69x.x1
A21 Screw, Phil Pan Shoulder #8-18x17/32" 900,301,98x.x1
A22 Screw, Phil Pan #8-18x1/2 900,301,84x.x1
A28 Screw, Phil Flat 10-32x1/2 900,301,94x.x1
A29 Screw, Machine Brass 6-32x1/4 900,201,44x.x1
B5 Speed Nut 900,800,85x.x1
C5 Lock Washer, Split 3/8" 900,700,36x.x1
E1 Refrigeration Bolt 3/8-16x1" 900,400,44x.x1
F6 Pop Rivet, Aluminum 1/8" 901,100,53x.x1
