COLA MARKETING MACHINE SERVICE MANUAL
ITEM DESCRIPTION DNCB 600E DNCB 501E DNCB 276E
79" Wide 72" Wide 72" Narrow
12C Evaporator Fan Motor Bracket
All Styles 164,040,08x.x3 164,040,08x.x3 164,040,08x.x3
12D Evaporator Fan Blade
All Styles (AD775CW32S or FV775CW30S) 801,303,27x.x1 801,303,27x.x1 801,303,27x.x1
13A Chute Assy., Can/Bottle
Standard 624,070,10x.x3 624,070,10x.x3 624,070,00x.x3
13B Chute, Can/Bottle
All Styles 805,701,04x.x1 805,701,04x.x1 805,701,03x.x1
13C Chute Liner (Kydex), Can/Bottle
All Styles 801,903,62x.x1 801,903,62x.x1 801,903,57x.x1
13D Chute Bracket
All Styles 609,070,48x.x3 609,070,48x.x3 609,070,48x.x3
14A Foam Block, EPS
All Styles 903,300,77x.x1 903,300,77x.x1 903,300,70x.x1
14B Hinge Pocket Cover
All Styles 169,000,13x.x3 169,000,13x.x3 169,000,13x.x3
15 Journal
All Styles 176,072,11x.x3 176,072,11x.x3 NA
16 Shims
Flat Shim 3/16" (wide column) 801,809,72x.x1 801,809,72x.x1 NA
Flat Shim 3/32" (wide column) 801,809,81x.x1 801,809,81x.x1 NA
Can Stop Shim, Right (narrow column) 609,070,14x.x3 609,070,14x.x3 609,070,14x.x3
Bottle Shim, Right (narrow column) 609,070,15x.x3 609,070,15x.x3 609,070,15x.x3
Bottle Shim, Right (narrow column) Expose Stiffener 801,304,96x.x1 801,304,96x.x1 801,304,96x.x1
Angle Shim (wide column) 610,070,06x.x1 610,070,06x.x1 NA
Angle Shim (narrow column) 609,010,10x.x3 609,010,10x.x3 609,010,10x.x3
Rotor Shim 330 ml x 4 609,070,57x.x3 609,070,57x.x3 609,070,57x.x3
Shim 330 ml x 4 Can, Narrow Column 609,070,53x.x3 609,070,53x.x3 609,070,53x.x3
Shim 25 cl x 4 Can, Narrow Column 609,070,56x.x3 609,070,56x.x3 609,070,56x.x3
17 Rod and Spring Assy. (narrow column)
All Styles 609,070,30x.x3 609,070,30x.x3 609,070,30x.x3
18 Tubes for Rod and Springs
Red 801,903,23x.x1 801,903,23x.x1 801,903,23x.x1
Yellow 801,903,25x.x1 801,903,25x.x1 801,903,25x.x1
White 801,903,24x.x1 801,903,24x.x1 801,903,24x.x1
19 Oscillator, Paddle Extension w/bottle stop
All Styles for advised set-up 324,010,21x.x3 324,010,21x.x3 NA
20 Bottle Divider
All Styles for advised set-up 609,072,40x.x3 609,072,30x.x3 609,072,30x.x3
21 Trim, Vend Motor Cover
All Styles 801,807,85x.x1 801,807,85x.x1 801,807,85x.x1
A3 Screw, Phil Pan 10-32x5/16" 900,301,83x.x1
A6 Screw, Vend Motor #4-24x3/4" (Single Switch) 900,300,47x.x1
A7 Screw, Vend Motor #4-24x1 1/16" (Double Switch) 900,301,82x.x1
A8 Screw, Vend Motor #4-24x1 1/2" (Triple Switch) 900,301,61x.x1
A9 Screw, Phil Pan 8-32x3/8 900,301,56x.x1
A12 Screw, Phil Thread 8-32x5/8 900,301,85x.x1
A18 Screw, Hex Head 8-36x3/8" 900,301,69x.x1
A19 Screw, Phil Pan 10-32x5/8" 900,901,51x.x1
