dji AVATA User Manual

DJI Avata
User Manual
54
© 2022 DJI All Rights Reserved.
DJI FPV Remote Controller 2
Built-into the DJI FPV Remote Controller 2 is DJI O3+ transmission technology, oering a maximum transmission
range of 6 mi (10 km). The buttons make control of the aircraft and camera eortless while the detachable control
sticks allow for the remote controller to be easily stored.
Operation
Powering On/O
Press the power button once to check the current battery level. If the battery level is too low, recharge before use.
Press once then press again and hold for two seconds to power the remote controller on or o.
Gimbal Dial
Shutter/Record Button
Charging the Battery
Use a USB-C cable to connect a charger to the USB-C port of the remote controller.
Controlling the Camera
1. Shutter/Record Button: Press once to take a photo or to start or stop recording. Press and hold to switch
between photo and video mode.
2. Gimbal Dial: Control the tilt of the gimbal.

dji AVATA Specifications

General

Type	Quadcopter
Certification	CE
Product color	Black, Grey
Construction type	Ready-to-fly (RTF)
Suitable for outdoor use	Yes
Maximum speed	- m/s
Number of rotors	4 rotors
Maximum weight capacity	- kg
Maximum operating distance	10000 m
Number of propeller blades	5
Megapixel	- MP
Sensor type	CMOS
Maximum frame rate	100 fps
Optical sensor size	1/1.7 \
Supported video modes	1080p
Video formats supported	H.265
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	155 °
Bitrate at maximum video resolution	50 Mbit/s
Memory card slot(s)	-
Moving control functions	Backward, Downward, Flying sideways, Forward, Turn left, Turn right, Upward
Operating time	120 min
Number of batteries supported	1

Weight and Dimensions

Weight	1000 g
