2018 DJI All Rights Reserved.
31
INSPIRE 2
SERIES User Manual
Connecting Batteries
Press the release button and open the corresponding charging port cover. Insert the Intelligent
Flight Battery into the charging port to begin charging. The battery pair with more stored power
will be charged rst. The Charging Hub will intelligently charge batteries in sequence according to
battery power levels from high to low, if batteries are not paired. Pairing can be carried out using
the DJI GO 4 app. Refer to the "Status LED Description” section for more information about Status
LED blinking patterns. The buzzer will begin beeping when charging is complete. Refer to the
“Buzzer Beeping Description” for more information about buzzer beeping patterns.
Always align the grooves on the Intelligent Flight Battery with the battery slot tracks.
Press the release button to detach batteries after charging is complete.
DO NOT leave metal terminals exposed to open air when not in use.
Status LED Descriptions
Status LED (Charging Hub) Description
Blinks Green Charging
— Solid Green Fully charged
Blinks Red Battery Charger Error. Retry with an ofcial battery charger.
— Solid Red Intelligent Flight Battery error
Blinks Yellow
Battery temperature too high/low. Temperature must be within
operating range (5°-40℃)
— Solid Yellow Ready to charge
Alternating Green Blinks Intelligent Flight Battery not detected
Battery Level Indicators while Charging (Battery)
LED1 LED2 LED3 LED4 Battery Level
0%~50%
50%~75%
75%~100%
Fully Charged
LED1
LED3
LED2
LED4
Battery Level Button
* It will take approximately 1.5 hours to fully charge the Inspire 2 Intelligent Flight Battery, and 3 hours for the
remote controller. It will take a longer time to charge the Intelligent Flight Battery and remote controller together.
