Appendix
Specications
Aircraft
Model T650A
Weight 7.58 lbs (3440 g, including two batteries, without gimbal and camera)
Max Takeoff Weight 4250 g
GPS Hovering Accuracy
Vertical: ±1.64 feet (0.5 m) or ±0.33 feet (0.1 m, Downward Vision
System enabled)
Horizontal: ±4.92 feet (1.5 m) or ±0.98 feet (0.3 m, Downward Vision
System enabled)
Max Angular Velocity
Pitch: 300°/s
Yaw: 150°/s
Max Tilt Angle
P-mode: 35° (Forward Vision System enabled: 25°); A-mode: 35°;
S-mode: 40°
Max Ascent Speed P-mode/A-mode: 16.4 ft/s (5 m/s); S-mode: 19.7 ft/s (6 m/s)
Max Descent Speed Vertical: 13.1 ft/s (4 m/s); Tilt: 13.1-29.5 ft/s (4-9 m/s)
Max Takeoff Sea Level 1.55 mi (2500 m); 3.1 mi (5000 m with specially-designed propeller)
Max Wind Speed Resistance 10 m/s
Max Flight Time Approx. 25 min (with Zenmuse X5S); Approx. 23 min (with Zenmuse X7)
Motor Model DJI 3512
Propeller Model DJI 1550T
Indoor Hovering Enabled by default
Operating Temperature -4° to 104° F (-20° to 40° C)
Diagonal Distance
(propeller excluded)
23.8 inch (605 mm, Landing Mode)
Max Speed 58 mph (94 kph)
Gimbal and Camera (Optional, take the Zenmuse X5S for example)
General
Name Zenmuse X5S
Dimensions 140×98×132 mm
Weight
Approx. 461 g( Including original lens, balancing ring, lens hood)
Camera
Supported Lens
DJI MFT 15mm/1.7 ASPH (With Balancing Ring and Lens Hood)
Panasonic Lumix 15mm/1.7 (With Balancing Ring and Lens Hood)
Panasonic Lumix 14-42mm/3.5-5.6 HD (With Balancing Ring)Olympus
M.Zuiko 12mm/2.0 (With Balancing Ring)
Olympus M.Zuiko 17mm/1.8 (With Balancing Ring)
Olympus M.Zuiko 25mm/1.8 (With Balancing Ring)
Olympus M.Zuiko 45mm/1.8 (With Balancing Ring)
Olympus M.Zuiko 9-18mm/4.0-5.6 (With Balancing Ring)
Sensors CMOS, 4/3” Effective Pixels: 20.8MP
