dji Inspire 2 Series User Manual

8
©
2018 DJI All Rights Reserved.
INSPIRE 2 SERIES User Manual
Preparing Remote Controller
Tilt the Mobile Device Holder to the desired position then adjust the antenna as shown.
1. Press the button on the side of the Mobile Device Holder to release the clamp, adjust it to t then
attach your mobile device.
2. Connect your mobile device to the remote controller with a USB cable.
3. Plug one end of the cable into your mobile device, and the other end into the USB port on the
back of the remote controller.
Attaching 1550T Quick Release Propellers
Following the steps below to attach the 1550T quick release propellers.
1. Pair the propellers and motors with arrows of the same color (red or white).
Press down the spring pad and rotate
the propeller lock until the arrows are
aligned and you hear a click.
Attach the propeller
onto the motor.
Again, rotate the propeller lock
until you hear a click.
2
3
1
Make sure to press down the spring pad before rotating the propeller lock.
3
1
2

dji Inspire 2 Series Specifications

General

Battery Capacity	4280 mAh
Battery Voltage	22.8 V
Operating Temperature	-20°C to 40°C
Camera Compatibility	Zenmuse X7, Zenmuse X5S, Zenmuse X4S
Transmission Distance	7 km (FCC), 4 km (CE)
Max Ascent Speed	5 m/s
Max Descent Speed	4 m/s
Operating Frequency	2.4 GHz and 5.8 GHz
Gimbal	3-axis
Satellite Systems	GPS/GLONASS
Charging Temperature Range	5°C to 40°C
Live View Quality	1080p
Max Tilt Angle	35°
Transmitter Power (EIRP)	26 dBm (FCC), 20 dBm (CE)
Video Transmission System	DJI Lightbridge
