dji Inspire 2 Series User Manual

50
©
2018 DJI All Rights Reserved.
INSPIRE 2 SERIES User Manual
3. Power on the aircraft.
4. Information about the CINESSD will be available in the DJI GO™ 4 app.
Exporting Files
1. Power off the aircraft. Remove the batteries and then the CINESSD.
2. Insert the CINESSD into the DJI CINESSD Station, then connect the station to a computer via a
USB cable.
c *0.1
1
2
USB Port
Using CINESSD
Using an Inspire 2 as an example.
Storing Files
1. Power off the aircraft.
2. Insert the CINESSD into the aircraft. If the CINESSD is not detected, check if it is inserted correctly.

dji Inspire 2 Series Specifications

General

Battery Capacity	4280 mAh
Battery Voltage	22.8 V
Operating Temperature	-20°C to 40°C
Camera Compatibility	Zenmuse X7, Zenmuse X5S, Zenmuse X4S
Transmission Distance	7 km (FCC), 4 km (CE)
Max Ascent Speed	5 m/s
Max Descent Speed	4 m/s
Operating Frequency	2.4 GHz and 5.8 GHz
Gimbal	3-axis
Satellite Systems	GPS/GLONASS
Charging Temperature Range	5°C to 40°C
Live View Quality	1080p
Max Tilt Angle	35°
Transmitter Power (EIRP)	26 dBm (FCC), 20 dBm (CE)
Video Transmission System	DJI Lightbridge
