MAVIC 2 ENTERPRISE Advanced
User Manual
16
©
2021 DJI All Rights Reserved.
The Front LEDs show the orientation of the aircraft and glow solid red when the aircraft is powered on
to indicate the front of the aircraft. Go to settings in DJI Pilot to turn the Front LEDs on or o.
The Aircraft Status Indicators communicate the status of the ight control system of the aircraft. Refer to
the table below for more information about the Aircraft Status Indicators. The Aircraft Status Indicators
also ash when the Home Point is being recorded as described in the Return to Home section.
Aircraft LEDs and Status Indicator
Mavic 2 Enterprise Advanced has Front LEDs and Aircraft Status Indicators as shown in the gure below.
Aircraft Status Indicator States
Normal States
Blinks red, green, and yellow
continuously
Powering on and performing self-diagnostic
tests
Blinks yellow and green alternately Warming up
Blinks green slowly P-mode with GPS
×2 Blinks yellow twice continuously
P-mode with Forward and Downward Vision
Systems
Blinks yellow slowly
No GPS, Forward Vision System, or
Downward Vision System
Blinks green quickly Braking
Blinks green and blue alternately RTK enabled and RTK data is being used
Warning States
Blinks yellow quickly Remote controller signal lost
Blinks red slowly Low battery
Blinks red quickly Critically low battery
Blinks red IMU error
—
Solid red Critical error
Blinks red and yellow alternately Compass calibration required
Blinks red and green alternately RTK enabled but RTK data unavailable
For missions that require concealed ight, enter camera settings in DJI Pilot and select Smart Arm
LEDs and turn all the LEDS o.
Aircraft Status Indicator
Front LEDs
Aircraft Status Indicator
Front LEDs
