dji MAVIC 2 ENTERPRISE Advanced User Manual

60
©
2021 DJI All Rights Reserved.
Appendix
Specications
Aircraft
Takeo Weight (excl. accessories) 909 g
Max Takeo Weight 1100 g
Dimensions Folded: 214×91×84 mm
Unfolded: 322×242×84 mm
Diagonal Distance 354 mm
Max Ascent Speed 6 m/s (S-mode)
5 m/s (P-mode)
Max Descent Speed Vertical Descent
5 m/s (S-mode)
4 m/s (P-mode)
Tilt
7 m/s (S-mode)
4 m/s (P-mode)
Max Speed 72 kph (S-mode, without wind)
Max Service Ceiling Above Sea Level 6000 m
Max Flight Time 31 min (measured while ying at 25 kph in windless conditions)
28 min (RTK module attached)
29 min (with beacon powered on) 30 min (with beacon powered o)
24 min (with spotlight powered on) 28 min (with spotlight powered o)
27 min (with speaker powered on) 28 min (with speaker powered o)
Max Wind Speed Resistance 10 m/s (scale 5)
Max Tilt Angle 35° (S-mode, with remote controller)
25° (P-mode)
Max Angular Velocity 200°/s (S-mode)
100°/s (P-mode)
Operating Temperature Range 14° to 104° F (-10° to 40° C)
GNSS GPS+GLONASS
Hovering Accuracy Range Vertical:
± 0.1 m (with RTK)
± 0.1 m (with Vision Positioning)
± 0.5 m (with GPS Positioning)
Horizontal:
± 0.1 m (with RTK)
± 0.3 m (with Vision Positioning)
± 1.5 m (with GPS Positioning)
Operating Frequency 2.4-2.4835 GHz; 5.725-5.850 GHz
Transmitter Power (EIRP) 2.4 GHz
FCC: ≤26 dBm; CE: ≤20 dBm; SRRC: ≤20 dBm; MIC: ≤20 dBm
5.8 GHz
FCC: ≤26 dBm; CE: ≤14 dBm; SRRC: ≤26 dBm
Internal Storage 24 GB

dji MAVIC 2 ENTERPRISE Advanced Specifications

General

Type	Quadcopter
Foldable	Yes
Product color	Gray
Construction type	Ready-to-fly (RTF)
Charging time	90 min
Battery voltage	15.4 V
Battery capacity	3850 mAh
Transmitter battery capacity	5000 mAh
Cables included	AC, USB Type-C
Maximum speed	20 m/s
Frequency band	2.4 - 5.85 GHz
Number of axis	3
Number of rotors	4 rotors
Maximum flight time	31 min
Maximum ascent speed	6 m/s
Maximum descent speed	7 m/s
Maximum flight altitude	6000 m
Maximum weight capacity	- kg
Maximum wind resistance	10 m/s
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum yaw angular velocity	200 °/sec
Megapixel	48 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160 pixels
Optical sensor size	1/2 \
Camera shutter speed	2/3/5/7/10/15/20/30/60 s
Image formats supported	JPEG
Video formats supported	MP4
Maximum image resolution	8000 x 6000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	87 °
Operating temperature (T-T)	-10 - 40 °C
Internal memory	24 GB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Built-in processor	-

Weight and Dimensions

Depth	455 mm
Width	290 mm
Height	225 mm
Weight	1710 g
Battery weight	297 g
Transmitter weight	630 g
Takeoff weight (max)	1100 g
