MAVIC 2 ENTERPRISE Advanced

User Manual

Charging the Battery

There are two pairs of built-in 18650 Li-ion batteries in the remote controller. Charge the remote

controller using the USB-C port.

Charging Time: approx. 2 hours and 15 minutes. (using a standard USB charger adapter )

Use a DJI official USB power adapter to charge the remote controller. If a DJI official adaptor is

unavailable, using a certied FCC/CE rated 12V/2A USB adapter is recommended.

The battery will deplete when stored for an extended period. Recharge the battery at least once every

three months to prevent over discharge.

Operating the Camera

Shoot photos and videos with the focus/shutter button and record button on the remote controller.

1. Focus/Shutter Button

Press to take a photo.

2. Record Button

Press once to start recording video and press again to stop.

3. Camera Settings Dial

Turn to adjust the zoom of the camera.

Power Outlet

100~240 V

USB Charger USB-C Cable

Controlling the Aircraft

The control sticks control the aircraft’s orientation (yaw), forward and backward movement (pitch),

altitude (throttle), and left and right movement (roll). The control stick mode determines the function

of each control stick. There are three pre-programmed modes as well as custom modes that can be

congured in DJI Pilot. The modes are Mode 1, Mode 2, and Mode 3. The default mode is Mode 2. In

each of the three pre-programmed modes, the aircraft hovers in place at a constant orientation when

both sticks are centered. See the gures below to check the function of each control stick in the three

pre-programmed modes.

Other manuals for dji MAVIC 2 ENTERPRISE Advanced

Questions and Answers:

Need help?

Do you have a question about the dji MAVIC 2 ENTERPRISE Advanced and is the answer not in the manual?

General

Type	Quadcopter
Foldable	Yes
Product color	Gray
Construction type	Ready-to-fly (RTF)
Charging time	90 min
Battery voltage	15.4 V
Battery capacity	3850 mAh
Transmitter battery capacity	5000 mAh
Cables included	AC, USB Type-C
Maximum speed	20 m/s
Frequency band	2.4 - 5.85 GHz
Number of axis	3
Number of rotors	4 rotors
Maximum flight time	31 min
Maximum ascent speed	6 m/s
Maximum descent speed	7 m/s
Maximum flight altitude	6000 m
Maximum weight capacity	- kg
Maximum wind resistance	10 m/s
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum yaw angular velocity	200 °/sec
Megapixel	48 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160 pixels
Optical sensor size	1/2 \
Camera shutter speed	2/3/5/7/10/15/20/30/60 s
Image formats supported	JPEG
Video formats supported	MP4
Maximum image resolution	8000 x 6000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	87 °
Operating temperature (T-T)	-10 - 40 °C
Internal memory	24 GB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Built-in processor	-
