dji MAVIC 2 ENTERPRISE Advanced User Manual

MAVIC 2 ENTERPRISE Advanced
User Manual
64
©
2021 DJI All Rights Reserved.
Charging Time 1 hour 30 minutes
Max Charging Power 80 W
Intelligent Flight Battery
Input 100-240 V, 50-60 Hz, Max. 0.8 A
Output Main: 17.6 V
3.41 A or 17.0 V 3.53 A
USB: 5 V
2 A
Rated Power 60 W
APP
Name DJI Pilot (Android version)
Video Transmission System OcuSync 2.0
Live View Quality 720p@30fps
Latency (depending on environment
and mobile device)
120 - 130 ms
M2EA RTK Module
Dimensions 69×69×59 mm
Port Type USB Micro-B
Power Approx. 3 W
GNSS GPS L1/L2, GLONASS F1/F2, BDS B1/B2, GALILEO E1/E5
RTK Position Accuracy In RTK FIX
1cm+1ppm (Horizontal) <br> 1.5cm+1ppm (Vertical)
M2E Beacon
Dimensions 68×40×27.8 mm
Port Type USB Micro-B
Power Avg. 1.6 W
Illuminance Min. angle: 55 cd; light intensity: 157 cd
Max. Visible Distance 5,000 m (with good air quality and high visibility)
M2E Spotlight
Dimensions 68×60×41 mm
Port Type USB Micro-B
Power Max. 26 W
Illuminance FOV 17°, max. 11 lux @ 30 m straight
Illumination area 30 m
M2E Speaker
Dimensions 68×55×65 mm
Port Type USB Micro-B
Power Max. 10 W
Decibel 100 dB at 1 m (international standard)
Bit Rate 16 kbps
* The DJI Smart Controller supports a microSD with a capacity of up to 128 GB.

dji MAVIC 2 ENTERPRISE Advanced Specifications

General

Type	Quadcopter
Foldable	Yes
Product color	Gray
Construction type	Ready-to-fly (RTF)
Charging time	90 min
Battery voltage	15.4 V
Battery capacity	3850 mAh
Transmitter battery capacity	5000 mAh
Cables included	AC, USB Type-C
Maximum speed	20 m/s
Frequency band	2.4 - 5.85 GHz
Number of axis	3
Number of rotors	4 rotors
Maximum flight time	31 min
Maximum ascent speed	6 m/s
Maximum descent speed	7 m/s
Maximum flight altitude	6000 m
Maximum weight capacity	- kg
Maximum wind resistance	10 m/s
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum yaw angular velocity	200 °/sec
Megapixel	48 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160 pixels
Optical sensor size	1/2 \
Camera shutter speed	2/3/5/7/10/15/20/30/60 s
Image formats supported	JPEG
Video formats supported	MP4
Maximum image resolution	8000 x 6000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	87 °
Operating temperature (T-T)	-10 - 40 °C
Internal memory	24 GB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Built-in processor	-

Weight and Dimensions

Depth	455 mm
Width	290 mm
Height	225 mm
Weight	1710 g
Battery weight	297 g
Transmitter weight	630 g
Takeoff weight (max)	1100 g
