dji MAVIC 2 ZOOM User Manual

Mavic 2 Pro/Zoom User Manual
©
2018 DJI All Rights Reserved.
35
Checking Battery Level
The battery level LEDs display how much charge remains. If the battery is turned o, press the Power
button, and the battery level LEDs light up to display the current battery level
Powering On/O
Press the Power button once, then press again, and hold for two seconds to turn the battery on or o.
Low Temperature Notice
1. Battery capacity is signicantly reduced when ying in low-temperature environments of 14° to 41° F
(-10° to 5° C). It is recommended to hover the aircraft in place for a while to heat the battery. Ensure
to fully charge the battery before takeo.
2. Batteries cannot be used in extremely low-temperature environments of < 14° F (-10° C).
3. When in low-temperature environments, end the ight as soon as DJI GO 4 displays the low battery
level warning.
4. To ensure optimal performance of the battery, keep the battery temperature above 68° F (20° C).
5. The reduced battery capacity in low-temperature environments reduces the aircraft's wind speed
resistance performance. Please y with caution.
6. Fly with extra caution at a high sea level.
In cold environments, insert the battery into the battery compartment and turn on the aircraft for
approximately 1 to 2 minutes to warm up before taking off.
Charging the Battery
Fully charge the Intelligent Flight Battery before using for the rst time:
1. Connect the AC power adapter to a power source (100-240 V, 50/60 Hz).
2. Attach the Intelligent Flight Battery to the AC power adapter using the battery charging cable with
the battery powered o.
3. The battery level LEDs display the current battery level during charging.
4. The Intelligent Flight Battery is fully charged when the battery level LEDs are all turned o. Detach the
AC power adapter when the battery is fully charged.
Charging Time: 1 hour and 30 minutes.
DO NOT charge an Intelligent Flight Battery immediately after flight as the temperature may be too
high. Wait until it cools down to room temperature before charging again.
The AC power adapter stops charging the battery if the battery cell temperature is not within the
operating range of 41° to 104° F (5° to 40° C). The ideal charging temperature is 71.6° to 82.4° F
(22° to 28° C).
The Battery Charging Hub (not included) can charge up to four batteries. Please visit the official
DJI Online Store to learn more.
AC Power Adapter
Intelligent Flight Battery
Power Outlet

dji MAVIC 2 ZOOM Specifications

General

Megapixel	12 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160 pixels
Maximum frame rate	120 fps
Optical sensor size	1/2.3 \
Camera shutter speed	8 – 1/8000 s
Streaming capability	Yes
Supported video modes	1080p, 2160p
Image formats supported	DNG, JPEG, RAW
Video formats supported	AVC, H.264, H.265, HEVC, MOV, MP4
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	83 °
Bitrate at maximum video resolution	100 Mbit/s
Built-in processor	-
Type	Quadcopter
Product color	Gray
Construction type	Ready-to-fly (RTF)
Moving control functions	Backward, Downward, Forward, Turn left, Turn right
USB ports quantity	1
Operating frequency	2400 - 2483, 5725 - 5850 MHz
Maximum device width	160 mm
Maximum speed	20 m/s
Frequency band	2.400 - 2.483, 5.725 - 5.850 GHz
Number of axis	3
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	29 min
Maximum flight time	31 min
Maximum ascent speed	5 m/s
Maximum descent speed	3 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10 m/s
Vertical hover accuracy	0.5 m
Horizontal hover accuracy	1.5 m
Maximum operating distance	8000 m
Maximum pitch angular velocity	200 °/sec
Battery voltage	15.4 V
Battery capacity	3850 mAh
Transmitter battery capacity	3950 mAh
Output power	60 W
AC adapter power	80 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.41 A
AC adapter output voltage	17.6 V
Equivalent Isotropically Radiated Power (EIRP)	26 dBmW
Operating temperature (T-T)	-10 - 40 °C
Cables included	Lightning, Micro-USB, USB Type-C
Internal memory	8 GB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB

Weight and Dimensions

Depth	322 mm
Width	242 mm
Height	84 mm
Weight	905 g
Battery weight	297 g
