2018 DJI All Rights Reserved.
61
Appendix
Specifications
Aircraft
Takeo Weight 907 g (Mavic 2 Pro); 905 g (Mavic 2 Zoom)
Dimensions Folded:
214×91×84 mm (length×width×height)
Unfolded:
322×242×84 mm (length×width×height)
Diagonal Distance 354 mm
Max Ascent Speed 5 m/s (S-mode), 4 m/s (P-mode)
Max Descent Speed 3 m/s (S-mode), 3 m/s (P-mode)
Max Speed 72 km/h (S-mode) (near sea level, no wind)
Max Service Ceiling Above
Sea Level
6000 m
Max Flight Time 31 minutes (at a consistent 25 kph) (no wind)
Max Hovering Time 29 minutes (no wind)
Overall Flight Time 25 minutes ( In normal ight, 15% remaining battery level )
Max Flight Distance 18 km (at a consistent 50 kph) (no wind)
Max Wind Speed
Resistance
29–38 kph
Max Tilt Angle 35° (S-mode, with remote controller), 25° (P-mode)
Max Angular Velocity 200°/s
Operating Temperature
Range
-10°C - 40°C
GNSS GPS+GLONASS
Hovering Accuracy Range Vertical:
± 0.1 m (when vision positioning is active)
± 0.5 m (with GPS positioning)
Horizontal:
± 0.3 m (when vision positioning is active)
± 1.5 m (with GPS positioning)
Operating Frequency 2.400 - 2.4835 GHz
;
5.725 - 5.850 GHz
Transmission Power (EIRP) 2.4 GHz
FCC: ≤26 dBm; CE: ≤20 dBm; SRRC: ≤20 dBm; MIC: ≤20 dBm
5.8 GHz
FCC: ≤26 dBm; CE: ≤14 dBm; SRRC: ≤26 dBm
Internal Storage 8 GB
Gimbal
Mechanical Range Tilt: -135 to 45°, Pan: -100 to 100°, Roll: -45 to 45°
Controllable Range Tilt: -90 to 30°, Pan: -75 to 75°
Stabilization 3-axis (tilt, roll, pan)
Max Control Speed (tilt) 120°/s
Angular Vibration Range ±0.01° (Mavic 2 Pro) ; ±0.005° (Mavic 2 Zoom)
