dji MAVIC 2 ZOOM User Manual

Mavic 2 Pro/Zoom User Manual
46
©
2018 DJI All Rights Reserved.
Dual Remote Controller Mode (Coming soon)
The Mavic 2 Pro/Zoom supports Dual Remote Controller Mode, which allows two remote controllers to
connect to the same aircraft.
Both the Primary remote controller and the Secondary remote controller can control the orientation of
the aircraft and the movement of the gimbal and camera operation.
Please note the dierent operations of the Primary and Secondary remote controller listed below.
1. Gimbal Dial
Both the Primary remote controller and the Secondary remote controller can control the gimbal
dial, but the Primary remote controller has priority. For example, the Secondary remote controller is
unable to control the gimbal dial when the Primary remote controller is using the gimbal dial. After
the Primary remote controller has stopped controlling the gimbal dial for two seconds or more, the
Secondary remote controller can control the gimbal dial.
2. Control Stick
Both the Primary remote controller and the Secondary remote controller can control the orientation
of the aircraft using control sticks. The Primary remote controller has priority. The Secondary remote
controller is unable to control the aircraft’s orientation when the Primary remote controller is operating
the control sticks. After the control sticks are idle for two seconds or more, the Secondary remote
controller can control the aircraft’s orientation.
If the control sticks on the Primary remote controller are pushed down and inward, the motors of the
aircraft stop. If the same action is performed on the Secondary remote controller, however, the aircraft
does not respond.
The control sticks on the Primary remote controller need to be released so that the Secondary remote
controller can control the aircraft.
3. Flight Mode Switch
The ight mode can only be switched on the Primary remote controller. The Flight Mode Switch is
disabled on the Secondary remote controller.
4. DJI GO 4 Settings
The display and parameter settings for the Primary and Secondary remote controllers in DJI GO 4
are the same. The Secondary remote controller can only congure the ight controller, vision system,
video transmission, and Intelligent Flight Battery. Display and parameter settings for the Primary and
Secondary remote controllers are the same in DJI GO 4.

dji MAVIC 2 ZOOM Specifications

General

Megapixel	12 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160 pixels
Maximum frame rate	120 fps
Optical sensor size	1/2.3 \
Camera shutter speed	8 – 1/8000 s
Streaming capability	Yes
Supported video modes	1080p, 2160p
Image formats supported	DNG, JPEG, RAW
Video formats supported	AVC, H.264, H.265, HEVC, MOV, MP4
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	83 °
Bitrate at maximum video resolution	100 Mbit/s
Built-in processor	-
Type	Quadcopter
Product color	Gray
Construction type	Ready-to-fly (RTF)
Moving control functions	Backward, Downward, Forward, Turn left, Turn right
USB ports quantity	1
Operating frequency	2400 - 2483, 5725 - 5850 MHz
Maximum device width	160 mm
Maximum speed	20 m/s
Frequency band	2.400 - 2.483, 5.725 - 5.850 GHz
Number of axis	3
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	29 min
Maximum flight time	31 min
Maximum ascent speed	5 m/s
Maximum descent speed	3 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10 m/s
Vertical hover accuracy	0.5 m
Horizontal hover accuracy	1.5 m
Maximum operating distance	8000 m
Maximum pitch angular velocity	200 °/sec
Battery voltage	15.4 V
Battery capacity	3850 mAh
Transmitter battery capacity	3950 mAh
Output power	60 W
AC adapter power	80 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.41 A
AC adapter output voltage	17.6 V
Equivalent Isotropically Radiated Power (EIRP)	26 dBmW
Operating temperature (T-T)	-10 - 40 °C
Cables included	Lightning, Micro-USB, USB Type-C
Internal memory	8 GB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB

Weight and Dimensions

Depth	322 mm
Width	242 mm
Height	84 mm
Weight	905 g
Battery weight	297 g
