dji MAVIC 2 ZOOM User Manual

Mavic 2 Pro/Zoom User Manual
©
2018 DJI All Rights Reserved.
23
Keep the sensors clean at all times. DO NOT tamper with the sensors
.
Do not obstruct the Infrared
Sensing System.
The Vision System may not be able to recognize patterns on the ground in low light conditions
(less than 100 lux).
If the aircraft speed exceeds 31 mph (50kph), the Vision System does not have enough time to
brake and stop the aircraft at a safe distance from an obstacle.
If the aircraft experiences a collision, camera calibration is required. Calibrate the front cameras
if DJI GO 4 prompts you to do so.
Do not fly on days that are rainy, smoggy, or if there is no clear sight.
Check the following every time before takeoff:
a. Ensure there are no stickers or any other obstructions over the glass of the Infrared Sensing
and Vision System.
b. If there is any dirt, dust, or water on the glass of the Infrared Sensing and Vision System,
clean it with a soft cloth. Do not use any cleanser that contains alcohol.
c. Contact DJI Support if there is any damage to the glass of the Infrared Sensing and Vision
System.
The Upward Infrared Sensing System detects straight line distances, large obstacles such as
roofs, but cannot detect tiny obstacles such as leaves or electrical wires.
Do not obstruct the Downward Vision System and Downward Infrared Sensing System before
takeoff. Otherwise, the aircraft cannot take off again after landing and will have to be restarted.
Intelligent Flight Modes
The Mavic 2 Pro/Zoom supports Intelligent Flight Modes including Hyperlapse, QuickShots, ActiveTrack
2.0, Point of Interest (POI 2.0), Waypoint (coming soon), TapFly, and Cinematic Mode. Select an
Intelligent Flight Mode in DJI GO 4. Ensure the battery level is sucient and the aircraft is working on
P-mode when using the Intelligent Flight Modes.
Hyperlapse
Hyperlapse shooting modes include Free, Circle, Course Lock, and Waypoint.
09:29
ISO
SHUTTER
EV
WB
1600 0.31/8000 4K/244K/25
Position
CAPACITY
61%
12
P
Course Lock
Waypoint
In flight (GPS)
Free Circle
Hyperlapse

dji MAVIC 2 ZOOM Specifications

General

Megapixel	12 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160 pixels
Maximum frame rate	120 fps
Optical sensor size	1/2.3 \
Camera shutter speed	8 – 1/8000 s
Streaming capability	Yes
Supported video modes	1080p, 2160p
Image formats supported	DNG, JPEG, RAW
Video formats supported	AVC, H.264, H.265, HEVC, MOV, MP4
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	83 °
Bitrate at maximum video resolution	100 Mbit/s
Built-in processor	-
Type	Quadcopter
Product color	Gray
Construction type	Ready-to-fly (RTF)
Moving control functions	Backward, Downward, Forward, Turn left, Turn right
USB ports quantity	1
Operating frequency	2400 - 2483, 5725 - 5850 MHz
Maximum device width	160 mm
Maximum speed	20 m/s
Frequency band	2.400 - 2.483, 5.725 - 5.850 GHz
Number of axis	3
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	29 min
Maximum flight time	31 min
Maximum ascent speed	5 m/s
Maximum descent speed	3 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10 m/s
Vertical hover accuracy	0.5 m
Horizontal hover accuracy	1.5 m
Maximum operating distance	8000 m
Maximum pitch angular velocity	200 °/sec
Battery voltage	15.4 V
Battery capacity	3850 mAh
Transmitter battery capacity	3950 mAh
Output power	60 W
AC adapter power	80 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.41 A
AC adapter output voltage	17.6 V
Equivalent Isotropically Radiated Power (EIRP)	26 dBmW
Operating temperature (T-T)	-10 - 40 °C
Cables included	Lightning, Micro-USB, USB Type-C
Internal memory	8 GB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB

Weight and Dimensions

Depth	322 mm
Width	242 mm
Height	84 mm
Weight	905 g
Battery weight	297 g
