dji MAVIC 2 ZOOM User Manual

Mavic 2 Pro/Zoom User Manual
66
©
2018 DJI All Rights Reserved.
Ensure the aircraft is connected to the computer before powering on.
The firmware update will take around 15 minutes. It is normal that the gimbal goes limp,
aircraft status indicators blink, and the aircraft reboots. Please wait patiently until the update is
complete.
Ensure the computer has access to the Internet.
Before performing an update ensure the Intelligent Flight Battery has at least 50% power and
the remote controller has at least 30% power.
Do not disconnect the aircraft from the computer during an update.
For safety, always update the firmware to the latest version when an upgrade notification is
shown in DJI GO 4.
Firmware upgrade notifications will prompt you to proceed with an update immediately or to
update the firmware within three days. If you choose to ignore the current firmware update, you
are required to accept the prompted disclaimer. You further understand and agree that the data
includes but is not limited to user selection records and may be uploaded to and maintained on
a DJI designated server.
The remote control device may become unlinked from the aircraft after updating. Re-link the
remote control device and aircraft.
Be sure to check all connections and remove the propellers from the motors before performing
the firmware update. DO NOT disconnect the aircraft or remote controller from the computer or
internet while updating the firmware.
Remote Controller Status
BAT xx PCT Remote Controller battery level.
SHUTDOWN_ Remote controller is powering o.
CHARGING_ Remote controller is charging.
USB PLUGGED Mavic 2 has been connected to a computer.
FC U-DISK Flight Controller is reading data.
UPGRADING Upgrading.
BINDING Aircraft is binding with the remote controller.
Before Flight
CONNECTING_ The remote controller is connecting to the aircraft.
SYS INITING System is initiating.
READY TO GO Ready to take o.
Flight Mode
BEGINNER In Beginner Mode.
GPS MODE In P-GPS Mode.
OPTI MODE In P-OPTI Mode.
ATTI MODE In P-ATTI Mode.
SPORT MODE In Sport Mode.
Flight Status
TAKING OFF Taking o.
LANDING Landing.
GOING HOME Returning to Home.
Remote Controller LCD Screen Menu Information

dji MAVIC 2 ZOOM Specifications

General

Megapixel	12 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160 pixels
Maximum frame rate	120 fps
Optical sensor size	1/2.3 \
Camera shutter speed	8 – 1/8000 s
Streaming capability	Yes
Supported video modes	1080p, 2160p
Image formats supported	DNG, JPEG, RAW
Video formats supported	AVC, H.264, H.265, HEVC, MOV, MP4
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	83 °
Bitrate at maximum video resolution	100 Mbit/s
Built-in processor	-
Type	Quadcopter
Product color	Gray
Construction type	Ready-to-fly (RTF)
Moving control functions	Backward, Downward, Forward, Turn left, Turn right
USB ports quantity	1
Operating frequency	2400 - 2483, 5725 - 5850 MHz
Maximum device width	160 mm
Maximum speed	20 m/s
Frequency band	2.400 - 2.483, 5.725 - 5.850 GHz
Number of axis	3
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	29 min
Maximum flight time	31 min
Maximum ascent speed	5 m/s
Maximum descent speed	3 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10 m/s
Vertical hover accuracy	0.5 m
Horizontal hover accuracy	1.5 m
Maximum operating distance	8000 m
Maximum pitch angular velocity	200 °/sec
Battery voltage	15.4 V
Battery capacity	3850 mAh
Transmitter battery capacity	3950 mAh
Output power	60 W
AC adapter power	80 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.41 A
AC adapter output voltage	17.6 V
Equivalent Isotropically Radiated Power (EIRP)	26 dBmW
Operating temperature (T-T)	-10 - 40 °C
Cables included	Lightning, Micro-USB, USB Type-C
Internal memory	8 GB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB

Weight and Dimensions

Depth	322 mm
Width	242 mm
Height	84 mm
Weight	905 g
Battery weight	297 g
