Mavic 2 Pro/Zoom User Manual
©
2018 DJI All Rights Reserved.
63
Color Mode Dlog-M (10-bit), support HDR video
(HLG 10-bit)
D-Cinelike
Max Video Bitrate 100 Mbps 100 Mbps
Supported File System FAT32: ≤ 32 GB
exFAT: > 32 GB
FAT32: ≤ 32 GB
exFAT: > 32 GB
Photo Format JPEG / DNG (RAW) JPEG / DNG (RAW)
Video Format MP4 / MOV (MPEG-4 AVC/H.264,
HEVC/H.265)
MP4 / MOV (MPEG-4 AVC/H.264,
HEVC/H.265)
Supported SD Cards Micro SD
Supporting Micro SD with capacity
up to 128 GB and R/W speed up to
UHS-I Speed Grade 3
Micro SD
Supporting Micro SD with capacity
up to 128 GB and R/W speed up to
UHS-I Speed Grade 3
Operating Temperature
Range
-10°C to 40°C -10°C to 40°C
HDR Enhanced HDR, 14 EV HDR, 13 EV
Hyperlight 8dB SNR 8dB SNR
Panorama Pano (3×1):
4000×6000 (40°×80°)
W (3×3)):
8000×6000 (113°×80°)
180° (3×7)):
8192×2840 (240°×76°)
Sphere (3×8+1)):
8192×4096 (360°×126°, 360°×180°)
Pano (3×1)):
4000×6000 (41°×93°)
W (3×3)):
8000×6000 (117°×93°)
180° (3×7)):
8192×2840 (249°×87°)
Sphere): (3×8+1) 8192×4096
(360°×126°, 360°×180°)
Super Resolution): 8000×6000 (24 mm
equivalent FOV)
Remote Controller
Operating Frequency 2.400 - 2.4835 GHz; 5.725 - 5.850 GHz
Max Transmission Distance FCC: 8000 m; CE: 5000 m; SRRC: 5000 m; MIC: 5000 m
(unobstructed, free of interference)
Operating Temperature
Range
0°C - 40°C
Battery 3950 mAh
Transmission Power (EIRP) 2.400 - 2.4835 GHz
FCC
:
≤26 dBm; CE
:
≤20 dBm; SRRC
:
≤20 dBm; MIC: ≤20 dBm
5.725 - 5.850 GHz
FCC: ≤26 dBm; CE: ≤14 dBm; SRRC:≤26 dBm
Operating Current/Voltage 1800 mA @ 3.83 V
Supported Mobile Device
Size
Max length: 160 mm; max thickness: 6.5 – 8.5 mm
Supported USB Port Types Lightning, Micro USB (Type-B
)
, USB-C
Charger
Input 100-240 V, 50/60 Hz, 1.8 A
Output Main: 17.6 V 3.41 A or 17.0 V 3.53 A
USB: 5 V 2 A
Voltage 17.6±0.1 V or 17.0 V±0.1 V

Other manuals for dji MAVIC 2 ZOOM

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the dji MAVIC 2 ZOOM and is the answer not in the manual?

dji MAVIC 2 ZOOM Specifications

General IconGeneral
Megapixel12 MP
Sensor typeCMOS
Video resolutions1920 x 1080, 3840 x 2160 pixels
Maximum frame rate120 fps
Optical sensor size1/2.3 \
Camera shutter speed8 – 1/8000 s
Streaming capabilityYes
Supported video modes1080p, 2160p
Image formats supportedDNG, JPEG, RAW
Video formats supportedAVC, H.264, H.265, HEVC, MOV, MP4
Maximum image resolution4000 x 3000 pixels
Maximum video resolution3840 x 2160 pixels
Field of view (FOV) angle83 °
Bitrate at maximum video resolution100 Mbit/s
Built-in processor-
TypeQuadcopter
Product colorGray
Construction typeReady-to-fly (RTF)
Moving control functionsBackward, Downward, Forward, Turn left, Turn right
USB ports quantity1
Operating frequency2400 - 2483, 5725 - 5850 MHz
Maximum device width160 mm
Maximum speed20 m/s
Frequency band2.400 - 2.483, 5.725 - 5.850 GHz
Number of axis3
Number of rotors4 rotors
Maximum tilt angle35 °
Hovering time (max)29 min
Maximum flight time31 min
Maximum ascent speed5 m/s
Maximum descent speed3 m/s
Maximum weight capacity- kg
Maximum wind resistance10 m/s
Vertical hover accuracy0.5 m
Horizontal hover accuracy1.5 m
Maximum operating distance8000 m
Maximum pitch angular velocity200 °/sec
Battery voltage15.4 V
Battery capacity3850 mAh
Transmitter battery capacity3950 mAh
Output power60 W
AC adapter power80 W
AC adapter frequency50/60 Hz
AC adapter input voltage100 - 240 V
AC adapter output current3.41 A
AC adapter output voltage17.6 V
Equivalent Isotropically Radiated Power (EIRP)26 dBmW
Operating temperature (T-T)-10 - 40 °C
Cables includedLightning, Micro-USB, USB Type-C
Internal memory8 GB
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size128 GB
Weight and Dimensions IconWeight and Dimensions
Depth322 mm
Width242 mm
Height84 mm
Weight905 g
Battery weight297 g
