dji MIC 2 User Manual

DJI Mic 2 User Manual
©
2024 DJI All Rights Reserved.
15
Using with a Computer
Connect the receiver to a computer via the USB-C port in order to use the transmitter as a
microphone.
• Use a standard charging cable or the DJI Mic 2 Mobile Phone Adapter (Type-C) to
connect DJI Mic 2 with a computer, and then enter the audio input settings for related
settings.
• DO NOT use the receiver for data storage. Otherwise, the data may be lost.

dji MIC 2 Specifications

General

Type	-
Noise reduction	Yes
Microphone frequency	50 - 20000 Hz
Equivalent noise level	21 dB
Microphone direction type	Omnidirectional
Maximum sound pressure level (1kHz)	120 dB
Device interface	Bluetooth
Connectivity technology	Wireless
Maximum operating distance	250 m
Product color	Black
Battery type	Built-in battery
Power source	Battery
Battery voltage	3.87 V
Battery capacity	360 mAh
Battery life (max)	6 h
Number of products included	2 pc(s)

Weight and Dimensions

Depth	30.96 mm
Width	46.06 mm
Height	21.83 mm
Microphone weight	28 g
Receiver dimensions (WxDxH)	54.2 x 28.36 x 22.49 mm
