DJI Mic 2 User Manual
6
©
2024 DJI All Rights Reserved.
6. Linking Button
Press and hold for two seconds to start linking to the receiver or mobile device via Bluetooth.
When connected to a mobile device, press once to take a photo or start or stop recording.
Note that only mobile devices where the volume button can be used to take a photo or start
and stop a video are supported.
7. Power Button
Press and hold for two seconds to power on or o. Press once to enable or disable noise
reduction.
8. Charging Pad
Charging will begin when the charging pad of a transmitter connects to the charging pins of
the DJI Mic 2 Charging Case.
LED Information
1
2
1
Recording Status LED
Blinking Pattern Descriptions
— Solid red The transmitter is recording independently.
Pulses red The transmitter has been muted.
O The transmitter is not recording independently.
2
System Status LED
Blinking Pattern Descriptions
Linking Status with DJI Mic 2 Receiver
— Solid green Linked with the receiver
Blinks green slowly Not linked with the receiver
Blinks green quickly Linking
Linking Status via Bluetooth
— Solid blue Linked with a Bluetooth device
Blinks blue slowly No Bluetooth device linked

dji MIC 2 Specifications

General

Type	-
Noise reduction	Yes
Microphone frequency	50 - 20000 Hz
Equivalent noise level	21 dB
Microphone direction type	Omnidirectional
Maximum sound pressure level (1kHz)	120 dB
Device interface	Bluetooth
Connectivity technology	Wireless
Maximum operating distance	250 m
Product color	Black
Battery type	Built-in battery
Power source	Battery
Battery voltage	3.87 V
Battery capacity	360 mAh
Battery life (max)	6 h
Number of products included	2 pc(s)

Weight and Dimensions

Depth	30.96 mm
Width	46.06 mm
Height	21.83 mm
Microphone weight	28 g
Receiver dimensions (WxDxH)	54.2 x 28.36 x 22.49 mm
