DJI Mic 2
User Manual
8
©
2024 DJI All Rights Reserved.
DJI Mic 2 Receiver
1. Touchscreen
Displays information such as real-time volume levels, battery levels of the receiver and
transmitters, charging status, wireless signal strength, gain, and recording modes. Swipe
up or down on the screen to access settings. Refer to Receiver Touchscreen Operation for
details.
2. Dial
When the receiver is on the home screen, press once then turn to adjust the transmitter or
receiver gain. Swipe down from the top of the screen to enter the Control Menu. Select and
conrm relevant settings by turning and pressing the dial.
3. Power Button
Press and hold to power on or off. Press once to lock or unlock the screen. When the
receiver screen is not on the home screen, press the power button once to return to the
home screen.
4. Monitor Port
Plug in 3.5 mm TRS headphones to monitor transmitter audio quality.
5. 3.5 mm TRS Output
For audio output.
6. Receiver Cold Shoe
For attaching the receiver to the cold shoe/hot shoe of a camera.
7. Data Port (USB-C)
After connecting to a computer, the data port can be used to update firmware or as a
microphone for the computer when paired with the transmitter. The data port can also be
used for charging.
8. Expansion Port
The receiver can be connected to a mobile device by inserting the mobile device adapter
into the expansion port. The receiver can be connected to a camera by plugging it into the
expansion port via a hot shoe adapter.
9. Charging Pad
Charging will begin when the charging pad of the receiver connects to the charging pins of
the DJI Mic 2 Charging Case.
1 2 3
4
5
6
7 8 9
