dji MIC 2 User Manual

DJI Mic 2 User Manual
©
2024 DJI All Rights Reserved.
27
Specications
DJI MIC 2 Transmitter
Model DMT02
Dimensions 46.06×30.96×21.83 mm (L×W×H)
Weight 28 g
Wireless Mode GFSK 1 Mbps and 2 Mbps
Equivalent Isotropic Radiated Power
(EIRP)
<20 dBm
Wireless Mode Operating Frequency 2.4000-2.4835 GHz
Bluetooth Protocol BR/EDR
Bluetooth Operating Frequency 2.4000-2.4835 GHz
Bluetooth Transmitter Power (EIRP) <20 dBm
Battery Type Li-ion
Battery Capacity 360 mAh
Battery Energy 1.39 Wh
Battery Voltage 3.87 V
Charging Temperature 5° to 45° C (41° to 113° F)
Operating Temperature -10° to 45° C (14° to 113° F)
Charging Time 70 mins
Operating Time 6 hours
[1]
DJI MIC 2 Receiver
Model DMR02
Dimensions 54.20×28.36×22.49 mm (L×W×H)
Weight 28 g
Wireless Mode GFSK 1 Mbps and 2Mbps
Equivalent Isotropic Radiated Power
(EIRP)
<20 dBm
Operating Frequency 2.4000-2.4835 GHz
Battery Type Li-ion
Battery Capacity 360 mAh
Battery Energy 1.39 Wh
Battery Voltage 3.87 V
Charging Temperature 5° to 45° C (41° to 113° F)
Operating Temperature -10° to 45° C (14° to 113° F)
Charging Time 70 mins
Operating Time 6 hours
[1]

dji MIC 2 Specifications

General

Type	-
Noise reduction	Yes
Microphone frequency	50 - 20000 Hz
Equivalent noise level	21 dB
Microphone direction type	Omnidirectional
Maximum sound pressure level (1kHz)	120 dB
Device interface	Bluetooth
Connectivity technology	Wireless
Maximum operating distance	250 m
Product color	Black
Battery type	Built-in battery
Power source	Battery
Battery voltage	3.87 V
Battery capacity	360 mAh
Battery life (max)	6 h
Number of products included	2 pc(s)

Weight and Dimensions

Depth	30.96 mm
Width	46.06 mm
Height	21.83 mm
Microphone weight	28 g
Receiver dimensions (WxDxH)	54.2 x 28.36 x 22.49 mm
