DJI Mic 2

User Manual

Linking the Transmitter and Receiver

In the DJI Mic 2 (2 TX + 1 RX + Charging Case) combo and DJI Mic 2 (1 TX + 1 RX) combo,

the transmitters and the receiver are linked by default. Follow the steps below to link the

transmitters and receiver if they become unlinked. The transmitters and the receiver can be

linked automatically by placing them in the charging case, or they can be linked manually.

• Before linking, make sure that the transmitter is in linking mode with the receiver. In

this mode, the system status LED blinks green slowly. The transmitter is in Bluetooth

linking mode when the system status LED of the transmitter blinks blue.

• Press and hold the record button for three seconds to switch between linking with the

DJI Mic 2 receiver or Bluetooth.

Method 1: Link automatically in the charging case

Place the transmitters and the receiver in the charging case to link them automatically.

RXTX

Questions and Answers:

Need help?

Do you have a question about the dji MIC 2 and is the answer not in the manual?

dji MIC 2 Specifications

General

Type	-
Noise reduction	Yes
Microphone frequency	50 - 20000 Hz
Equivalent noise level	21 dB
Microphone direction type	Omnidirectional
Maximum sound pressure level (1kHz)	120 dB
Device interface	Bluetooth
Connectivity technology	Wireless
Maximum operating distance	250 m
Product color	Black
Battery type	Built-in battery
Power source	Battery
Battery voltage	3.87 V
Battery capacity	360 mAh
Battery life (max)	6 h
Number of products included	2 pc(s)
