DJI Mic 2
User Manual
©
2024 DJI All Rights Reserved.
17
The middle of the screen indicates the status of the transmitters.
L
R
Indicates the sound channel.
Indicates the transmitter gain.
Indicates that noise reduction is enabled.
Indicates that the transmitter is recording independently.
Indicates the battery level of transmitter.
The bottom of the screen indicates the real-time volume.
Audio volume from the built-in microphone on the transmitter.
The transmitter has been muted.
Audio volume from the external microphone connected to the transmitter.
The external microphone connected to the transmitter has been muted.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the dji MIC 2 and is the answer not in the manual?

dji MIC 2 Specifications

General IconGeneral
Type-
Noise reductionYes
Microphone frequency50 - 20000 Hz
Equivalent noise level21 dB
Microphone direction typeOmnidirectional
Maximum sound pressure level (1kHz)120 dB
Device interfaceBluetooth
Connectivity technologyWireless
Maximum operating distance250 m
Product colorBlack
Battery typeBuilt-in battery
Power sourceBattery
Battery voltage3.87 V
Battery capacity360 mAh
Battery life (max)6 h
Number of products included2 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth30.96 mm
Width46.06 mm
Height21.83 mm
Microphone weight28 g
Receiver dimensions (WxDxH)54.2 x 28.36 x 22.49 mm
