18
©
2022 DJI All Rights Reserved.
DJI Mini 3 Pro
User Manual
Detection Range
Forward Vision System
Precision Measurement Range: 0.39-25 m; FOV: 106° (horizontal), 90° (vertical)
Backward Vision System
Precision Measurement Range: 0.36-23.4 m; FOV: 58° (horizontal), 73° (vertical)
Downward Vision System
Precision Measurement Range: 0.15-9 m; FOV: 104.8° (front and back), 87.6° (left and right). The
Downward Vision System works best when the aircraft is at an altitude of 0.5 to 12 m.
Forward Vision System
Backward Vision System
Downward
Vision System
Infrared Sensing System
106°
106°
104.8°
90°
87.6°
0.5-12 m
0.36-23.4 m
0.39-25 m
58°
58°
73°
87.6°
Landing Protection
Smart RTH or Auto Landing activates Landing Protection, which operates as follows:
1. Once Landing Protection determines that the ground is suitable for landing, the aircraft will land
gently.
2. If the ground is determined unsuitable for landing, the aircraft will hover and wait for pilot
conrmation.
3. If Landing Protection is not operational, DJI Fly will display a landing prompt when the aircraft
descends to 0.5 m from the ground. Push the throttle stick down for one second to land.
Landing Protection is activated during Failsafe RTH. The aircraft will hover 0.5 m above ground, and DJI
Fly will display a landing prompt. To land the aircraft, push the throttle stick down for one second.
Vision Systems and Infrared Sensing Systems
DJI Mini 3 Pro is equipped with both an Infrared Sensing System and Forward, Backward, and
Downward Vision Systems.
The Forward, Backward, and Downward Vision Systems consist of two cameras each.
The Infrared Sensing System consists of two 3D infrared modules. The Downward Vision System and
Infrared Sensing System help the aircraft maintain its current position, hover more precisely, and to y
indoors or in other environments where GNSS is unavailable.
