dji MINI 3 PRO User Manual

©
2022 DJI All Rights Reserved.
9
DJI Mini 3 Pro
User Manual
1. Forward Vision System
2. Gimbal and Camera
3. Downward Vision System
4. Infrared Sensing System
5. Propellers
6. Motors
7. Aircraft Status LEDs
8. Battery Buckles
9. Backward Vision System
10. Battery Level LEDs
11. Power Button
12. USB-C Port
13. microSD Card Slot
14. Intelligent Flight Battery
1
3
4
5
6
7
8
2
9
10
12
13
14
11
Binding the Aircraft and Remote Controller
After activation, the aircraft is bound to the remote controller automatically. If automatic binding fails,
follow the on-screen prompts on DJI Fly to bind the aircraft and remote controller for optimal warranty
services.
Updating Firmware
A prompt will appear in DJI Fly when new rmware is available. Update the rmware whenever
prompted to ensure optimal user experience.
Diagram
Aircraft

dji MINI 3 PRO Specifications

General

Weight	249 g
Max Flight Time	34 minutes
Dimensions (Folded)	145×90×62 mm
Dimensions (Unfolded)	251×362×70 mm
Max Ascent Speed	5 m/s
Max Descent Speed	5 m/s
Max Horizontal Speed	16 m/s
Max Wind Speed Resistance	10.7 m/s (Level 5)
Operating Frequency	2.400-2.4835 GHz, 5.725-5.850 GHz
Camera Sensor	1/1.3-inch CMOS
ISO Range Video	100-6400
ISO Range Photo	100-6400
Photo Resolution	48 MP (8064×6048)
Video Resolution	4K: 3840×2160@24/25/30/48/50/60fps
Gimbal	3-axis (tilt, roll, pan)
Video Transmission System	DJI O3
Live View Quality	1080p/30fps
Obstacle Sensing	Forward, backward, downward
Battery Capacity	2453 mAh
Max Flight Time with Plus Battery	47 minutes
Transmitter Power (EIRP)	2.4 GHz: <26 dBm
Camera Lens	FOV: 82.1°
Max Video Resolution	4K (3840×2160)
Max Transmission Range	12 km
Charging Time	64 minutes (with DJI 30W USB-C Charger)
Operating Temperature	0° to 40° C
Supported SD Cards	microSD
