dji MINI 3 PRO User Manual

14
©
2022 DJI All Rights Reserved.
DJI Mini 3 Pro
User Manual
Aircraft Status Indicator
DJI Mini 3 Pro has two aircraft status indicators.
When the aircraft is powered on but the motors are not running, the aircraft status indicators will
display the current status of the ight control system. Refer to the table below for more information
about the aircraft status indicators.
Aircraft Status Indicator Descriptions
Normal States
Alternating red, green,
and yellow
Blinks
Turning on and performing self-
diagnostic tests
×4
Yellow Blinks four times Warming up
Green Blinks slowly GNSS enabled
×2
Green Periodically blinks twice Vision Systems enabled
Yellow Blinks slowly NO GNSS or Vision Systems
Warning States
Yellow Blinks quickly Remote controller signal lost
Red Blinks slowly Low battery
Red Blinks quickly Critically low battery
——
Red Solid Critical error
Alternating red and yellow Blinks quickly Compass calibration required
After the motors start, the aircraft status indicators will blink green.
Lighting requirements vary depending on the region. Observe local laws and regulations.
Aircraft Status Indicator
Aircraft Status Indicator
QuickTransfer
DJI Mini 3 Pro can connect directly to mobile devices via Wi-Fi, enabling users to download photos and
videos from the aircraft to the mobile device through DJI Fly without using the DJI RC-N1 remote controller.
Users can enjoy faster and more convenient downloads with a transmission rate of up to 25 MB/s.
Usage
Method 1: mobile device is not connected to the remote controller
1. Power on the aircraft and wait until the self-diagnostic tests of the aircraft are complete.

dji MINI 3 PRO Specifications

General

Weight	249 g
Max Flight Time	34 minutes
Dimensions (Folded)	145×90×62 mm
Dimensions (Unfolded)	251×362×70 mm
Max Ascent Speed	5 m/s
Max Descent Speed	5 m/s
Max Horizontal Speed	16 m/s
Max Wind Speed Resistance	10.7 m/s (Level 5)
Operating Frequency	2.400-2.4835 GHz, 5.725-5.850 GHz
Camera Sensor	1/1.3-inch CMOS
ISO Range Video	100-6400
ISO Range Photo	100-6400
Photo Resolution	48 MP (8064×6048)
Video Resolution	4K: 3840×2160@24/25/30/48/50/60fps
Gimbal	3-axis (tilt, roll, pan)
Video Transmission System	DJI O3
Live View Quality	1080p/30fps
Obstacle Sensing	Forward, backward, downward
Battery Capacity	2453 mAh
Max Flight Time with Plus Battery	47 minutes
Transmitter Power (EIRP)	2.4 GHz: <26 dBm
Camera Lens	FOV: 82.1°
Max Video Resolution	4K (3840×2160)
Max Transmission Range	12 km
Charging Time	64 minutes (with DJI 30W USB-C Charger)
Operating Temperature	0° to 40° C
Supported SD Cards	microSD
