dji MINI 3 PRO User Manual

54
©
2022 DJI All Rights Reserved.
DJI Mini 3 Pro
User Manual
Camera View
1 2 3 4 5 6 7
15161718
19
20
11
12
9
10
8
13
14
1. Flight Mode
N: Displays the current ight mode.
2. System Status Bar
In Flight: Indicates the aircraft ight status and displays various warning messages. Tap to view more
information when a warning prompt appears.
3. Battery Information
80
24'17"
: Displays the current battery level and remaining ight time.
4. Video Downlink Signal Strength
RC
: Displays the video downlink signal strength between the aircraft and the remote controller.
5. Vision System Status
: The upper part of the icon indicates the status of the Forward Vision System, and the lower part
indicates the status of the Backward Vision System. The icon is white when the vision system is
working normally and turns red when the vision system is unavailable.
6. GNSS Status
20
: Displays the current GNSS signal strength. Tap to check the GNSS signal status. The Home
Point can be updated when the icon is white, which indicates the GNSS signal is strong.
7. System Settings
System settings provide information about safety, control, the camera, and transmission.
Safety
Flight Assistance: Forward and Backward vision systems are enabled after setting Obstacle
Avoidance to Bypass or Brake. The aircraft cannot sense obstacles if Obstacle Avoidance is
disabled. The aircraft cannot y left or right if Sideways Flight is disabled.
Radar Map Display: When enabled, the real-time obstacle detection radar map will be displayed.
Flight Protection: Tap to set the max altitude and the max distance for ights.
RTH: Tap to set the Return to Home Altitude and update the Home Point.

dji MINI 3 PRO Specifications

General

Weight	249 g
Max Flight Time	34 minutes
Dimensions (Folded)	145×90×62 mm
Dimensions (Unfolded)	251×362×70 mm
Max Ascent Speed	5 m/s
Max Descent Speed	5 m/s
Max Horizontal Speed	16 m/s
Max Wind Speed Resistance	10.7 m/s (Level 5)
Operating Frequency	2.400-2.4835 GHz, 5.725-5.850 GHz
Camera Sensor	1/1.3-inch CMOS
ISO Range Video	100-6400
ISO Range Photo	100-6400
Photo Resolution	48 MP (8064×6048)
Video Resolution	4K: 3840×2160@24/25/30/48/50/60fps
Gimbal	3-axis (tilt, roll, pan)
Video Transmission System	DJI O3
Live View Quality	1080p/30fps
Obstacle Sensing	Forward, backward, downward
Battery Capacity	2453 mAh
Max Flight Time with Plus Battery	47 minutes
Transmitter Power (EIRP)	2.4 GHz: <26 dBm
Camera Lens	FOV: 82.1°
Max Video Resolution	4K (3840×2160)
Max Transmission Range	12 km
Charging Time	64 minutes (with DJI 30W USB-C Charger)
Operating Temperature	0° to 40° C
Supported SD Cards	microSD
