DJI Mini 3 Pro
User Manual
Starting/Stopping the Motors
Starting the Motors
Perform the Combination Stick Command (CSC) as shown below to start the motors. Once the motors
have started spinning, release both sticks simultaneously.
OR
Stopping the Motors
The motors can be stopped in two ways:
Method 1: When the aircraft has landed, push the throttle stick down and hold. The motors will stop
after three seconds.
Method 2: When the aircraft has landed, push the throttle stick down, and perform the same CSC used
to start the motors. Release both sticks once the motors have stopped.
Stopping the Motors Mid-Flight
Stopping the motors mid-flight will cause the aircraft to crash. DO NOT stop the motors mid-flight
unless you encounter an emergency situation, for example, if a collision has occurred, or if the
aircraft is out of control and ascending or descending quickly, or the aircraft is rolling in the air. To
stop the motors mid-flight, perform the same CSC used to start the motors. The default setting
can be changed in DJI Fly.
Flight Test
Takeo/Landing Procedures
1. Place the aircraft in an open, at area with the rear of the aircraft facing towards you.
2. Power on the remote controller and the aircraft.
3. Launch DJI Fly and enter the camera view.
4. Wait for the aircraft self-diagnostics to complete. If DJI Fly does not show any irregular warning, you
can start the motors.
5. Push the throttle stick up slowly to take o.
6. To land, hover over a level surface and gently push the throttle stick down to descend.
Method 1 Method 2
OR

dji MINI 3 PRO Specifications

General

Weight	249 g
Max Flight Time	34 minutes
Dimensions (Folded)	145×90×62 mm
Dimensions (Unfolded)	251×362×70 mm
Max Ascent Speed	5 m/s
Max Descent Speed	5 m/s
Max Horizontal Speed	16 m/s
Max Wind Speed Resistance	10.7 m/s (Level 5)
Operating Frequency	2.400-2.4835 GHz, 5.725-5.850 GHz
Camera Sensor	1/1.3-inch CMOS
ISO Range Video	100-6400
ISO Range Photo	100-6400
Photo Resolution	48 MP (8064×6048)
Video Resolution	4K: 3840×2160@24/25/30/48/50/60fps
Gimbal	3-axis (tilt, roll, pan)
Video Transmission System	DJI O3
Live View Quality	1080p/30fps
Obstacle Sensing	Forward, backward, downward
Battery Capacity	2453 mAh
Max Flight Time with Plus Battery	47 minutes
Transmitter Power (EIRP)	2.4 GHz: <26 dBm
Camera Lens	FOV: 82.1°
Max Video Resolution	4K (3840×2160)
Max Transmission Range	12 km
Charging Time	64 minutes (with DJI 30W USB-C Charger)
Operating Temperature	0° to 40° C
Supported SD Cards	microSD
