DJI Mini 3 Pro
User Manual
It is recommended to use the DJI 30W USB-C Charger or other USB Power Delivery chargers.
The maximum charge voltage for the aircraft charging port is 12 V.
Make sure the gimbal protector is removed and all arms are unfolded before powering on the
aircraft. Otherwise, it may aect the aircraft self-diagnostics.
Attach the gimbal protector when the aircraft is not in use. Ensure all arms are folded before re-
attaching the gimbal protector. First rotate the camera to make it horizontal and forward-facing
①
. While attaching the gimbal protector, ensure the camera ts into the protector rst, then insert
the latch on the upper part of the protector onto the opening on the aircraft
②
, and insert the two
locating pins into the holes at the bottom of the aircraft
③
.
1
2
3
2. All Intelligent Flight Batteries are in hibernation mode before shipment to ensure safety. Connect the
USB charger to the USB-C port on the aircraft to charge and activate the Intelligent Flight Batteries
for the rst time.
3. Unfold the rear arms, followed by the front arms, and then all of the propeller blades.
Using for the First Time
DJI Mini 3 Pro is folded before being packaged. Follow the steps below to unfold the aircraft and remote
controller.
Preparing the Aircraft
All aircraft arms are folded before the aircraft is packaged. Follow the steps below to unfold the aircraft.
1. Remove the gimbal protector from the camera.

dji MINI 3 PRO Specifications

General

Weight	249 g
Max Flight Time	34 minutes
Dimensions (Folded)	145×90×62 mm
Dimensions (Unfolded)	251×362×70 mm
Max Ascent Speed	5 m/s
Max Descent Speed	5 m/s
Max Horizontal Speed	16 m/s
Max Wind Speed Resistance	10.7 m/s (Level 5)
Operating Frequency	2.400-2.4835 GHz, 5.725-5.850 GHz
Camera Sensor	1/1.3-inch CMOS
ISO Range Video	100-6400
ISO Range Photo	100-6400
Photo Resolution	48 MP (8064×6048)
Video Resolution	4K: 3840×2160@24/25/30/48/50/60fps
Gimbal	3-axis (tilt, roll, pan)
Video Transmission System	DJI O3
Live View Quality	1080p/30fps
Obstacle Sensing	Forward, backward, downward
Battery Capacity	2453 mAh
Max Flight Time with Plus Battery	47 minutes
Transmitter Power (EIRP)	2.4 GHz: <26 dBm
Camera Lens	FOV: 82.1°
Max Video Resolution	4K (3840×2160)
Max Transmission Range	12 km
Charging Time	64 minutes (with DJI 30W USB-C Charger)
Operating Temperature	0° to 40° C
Supported SD Cards	microSD
