DJI Mini 3 Pro
User Manual
Make sure to follow all the steps to update the rmware, otherwise the update may fail.
The rmware update will take approximately 10 minutes. It is normal for the gimbal to go limp, aircraft
status indicators to blink, and the aircraft to reboot. Wait patiently until the update is complete.
Make sure the computer is connected to the internet during the update.
Before performing an update, make sure the Intelligent Flight Battery has at least 40% power and the
remote controller 30%.
Do not unplug the USB-C cable during an update.
Aftersales Information
Visit https://www.dji.com/support to learn more about aftersales service policies, repair services, and
support.

dji MINI 3 PRO Specifications

General

Weight	249 g
Max Flight Time	34 minutes
Dimensions (Folded)	145×90×62 mm
Dimensions (Unfolded)	251×362×70 mm
Max Ascent Speed	5 m/s
Max Descent Speed	5 m/s
Max Horizontal Speed	16 m/s
Max Wind Speed Resistance	10.7 m/s (Level 5)
Operating Frequency	2.400-2.4835 GHz, 5.725-5.850 GHz
Camera Sensor	1/1.3-inch CMOS
ISO Range Video	100-6400
ISO Range Photo	100-6400
Photo Resolution	48 MP (8064×6048)
Video Resolution	4K: 3840×2160@24/25/30/48/50/60fps
Gimbal	3-axis (tilt, roll, pan)
Video Transmission System	DJI O3
Live View Quality	1080p/30fps
Obstacle Sensing	Forward, backward, downward
Battery Capacity	2453 mAh
Max Flight Time with Plus Battery	47 minutes
Transmitter Power (EIRP)	2.4 GHz: <26 dBm
Camera Lens	FOV: 82.1°
Max Video Resolution	4K (3840×2160)
Max Transmission Range	12 km
Charging Time	64 minutes (with DJI 30W USB-C Charger)
Operating Temperature	0° to 40° C
Supported SD Cards	microSD
