dji MINI 3 PRO User Manual

10
©
2022 DJI All Rights Reserved.
DJI Mini 3 Pro
User Manual
1
2
3
4
7
8
9
10
11
15
12
13
14
5
6
11. Gimbal Dial
Controls the tilt of the camera.
12. Record Button
Press once to start or stop
recording.
13. Camera Control Dial
For zoom control.
14. Focus/Shutter Button
Press halfway down on the
button to auto focus and press all the way
down to take a photo.
15. Speaker
Outputs sound.
16. Control Sticks Storage Slot
For storing the control sticks.
17. Customizable C2 Button
Switch between recentering the gimbal and
16
17 18
DJI RC Remote Controller
1
2
3
4
7
8
9
10
11
15
12
13
14
5
6
1. Control Sticks
Use the control sticks to control the
movement of the aircraft. The control sticks
are removable and easy to store. Set the
ight control mode in DJI Fly.
2. Status LED
Indicates the status of the remote
controller.
3. Battery Level LEDs
Displays the current battery level of the
remote controller.
4. Flight Pause/Return to Home (RTH) Button
Press once to make the aircraft brake and
hover in place (only when GNSS or Vision
Systems are available). Press and hold to initiate
RTH. Press again to cancel RTH.
5. Flight Mode Switch
Switch between Cine, Normal, and Sport mode.
6. Power Button
Press once to check the current battery level.
Press, and then press and hold to power the
remote controller on or off. When the remote
controller is powered on, press once to turn the
touchscreen on or o.
7. Touchscreen
Touch the screen to operate the remote
controller. Note that the touchscreen is not
waterproof. Operate with caution.
8. USB-C Port
For charging and connecting the remote
controller to your computer.
9. microSD Card Slot
For inserting a microSD card.
10. Host Port (USB-C) *
For connecting the DJI Cellular Dongle which
needs to be purchased separately.
* To be supported later through rmware
updates.

dji MINI 3 PRO Specifications

General

Weight	249 g
Max Flight Time	34 minutes
Dimensions (Folded)	145×90×62 mm
Dimensions (Unfolded)	251×362×70 mm
Max Ascent Speed	5 m/s
Max Descent Speed	5 m/s
Max Horizontal Speed	16 m/s
Max Wind Speed Resistance	10.7 m/s (Level 5)
Operating Frequency	2.400-2.4835 GHz, 5.725-5.850 GHz
Camera Sensor	1/1.3-inch CMOS
ISO Range Video	100-6400
ISO Range Photo	100-6400
Photo Resolution	48 MP (8064×6048)
Video Resolution	4K: 3840×2160@24/25/30/48/50/60fps
Gimbal	3-axis (tilt, roll, pan)
Video Transmission System	DJI O3
Live View Quality	1080p/30fps
Obstacle Sensing	Forward, backward, downward
Battery Capacity	2453 mAh
Max Flight Time with Plus Battery	47 minutes
Transmitter Power (EIRP)	2.4 GHz: <26 dBm
Camera Lens	FOV: 82.1°
Max Video Resolution	4K (3840×2160)
Max Transmission Range	12 km
Charging Time	64 minutes (with DJI 30W USB-C Charger)
Operating Temperature	0° to 40° C
Supported SD Cards	microSD
