dji Mini 3 User Manual

DJI Mini 3
User Manual
26
©
2022 DJI All Rights Reserved.
Using A Charger
1. Ensure the battery has been correctly installed on the aircraft.
2. Connect the USB charger to an AC outlet (100-240V, 50/60 Hz). Use a power adapter if
necessary.
3. Connect the USB charger to the charging port on the aircraft using a USB-C cable.
4. The battery level LEDs display the current battery level during charging.
5. The battery is fully charged when all the battery level LEDs emit a solid light. Remove the
charger after charging is complete.
•
The battery cannot be charged if the aircraft is powered on.
•
The maximum charge voltage for the aircraft charging port is 15 V.
•
DO NOT charge an Intelligent Flight Battery immediately after flight as it may be too
hot. Wait for the battery to cool down to room temperature before charging again.
•
The charger stops charging the battery if the cell temperature is not within 5° to 40° C
(41° to 104° F). The ideal charging temperature is from 22° to 28° C (71.6° to 82.4° F).
•
Fully charge the battery at least once every three months to maintain battery health.
It is recommended to use the DJI 30W USB-C Charger or other USB Power Delivery
chargers.
•
When using the DJI 30W USB-C Charger, the charging time for Mini 3 Pro Intelligent
Flight Battery is approximately 1 hour and 4 minutes, while for Mini 3 Pro Intelligent
Flight Battery Plus it is approximately 1 hour and 41 minutes.
•
For safety purposes, keep the batteries at a low power level in transit. Before
transportation, it is recommended to discharge the batteries to 30% or lower.
The table below shows the battery level LED statuses during charging.
LED1 LED2 LED3 LED4 Battery Level
1%-50%
51%-75%
76%-99%
100%
•
The blinking frequency of the battery level LEDs differs depending on the USB charger
used. If the charging speed is fast, the battery level LEDs will blink quickly.
•
If the battery is not correctly inserted into the aircraft, LEDs 3 and 4 will blink
simultaneously. Insert the battery again and make sure it is securely mounted.
•
The four LEDs blinking simultaneously indicates the battery is damaged.

dji Mini 3 Specifications

General

Type	Quadcopter
Foldable	Yes
Certification	FCC
Product color	Gray
Construction type	Ready-to-fly (RTF)
Maximum speed	10.55 m/s
Number of axis	3
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Number of rotors	4 rotors
Bluetooth version	5.2
Maximum tilt angle	40 °
Maximum ascent speed	5 m/s
Maximum descent speed	3.5 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10.7 m/s
Vertical hover accuracy	0.3 m
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum pitch angular velocity	250 °/sec
Megapixel	12 MP
Sensor type	CMOS
Digital zoom	4 x
Video resolutions	1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/1.3 \
Camera shutter speed	1/8000-2 s
Supported video modes	720p
Supported file systems	FAT32, exFAT
Angular vibration range	-0.01 - 0.01 °
Image formats supported	DNG, JPG
Maximum aperture number	1.7
Video formats supported	H.264
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	82.1 °
Bitrate at maximum video resolution	100 Mbit/s
Built-in processor	-
Compatible memory cards	MicroSD (TransFlash), MicroSDXC
Maximum memory card size	512 GB
Flight modes	Failsafe mode
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
USB ports quantity	1
Operating frequency	2400-24835, 5725-5850 MHz
Maximum device width	86 mm
Charging time	64 min
Operating time	38 min
Battery voltage	7.38 V
Battery capacity	2453 mAh
Transmitter battery capacity	5200 mAh
Cables included	Lightning, Micro-USB, USB, USB Type-C
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	362 mm
Width	251 mm
Height	72 mm
Weight	248 g
Battery weight	80.5 g
