dji Mini 3 User Manual

DJI Mini 3
User Manual
35
©
2022 DJI All Rights Reserved.
Flight Pause/RTH Button
Press once to make the aircraft brake and hover in place. Press and hold the button until the
remote controller beeps to start RTH, the aircraft will return to the last recorded Home Point.
Press this button again to cancel RTH and to regain control of the aircraft.
Flight Mode Switch
Toggle the switch to select the desired flight mode.
Position Flight Mode
S Sport Mode
N Normal Mode
C Cine Mode
CNS
Customizable Buttons
Go to System Settings in DJI Fly and select Control to set the functions of the customizable C1
and C2 buttons.
Status LED and Battery Level LEDs Description
Status LED
Blinking Pattern Description
—— Solid red Disconnected from the aircraft
Blinking red The battery level of the aircraft is low
—— Solid green Connected with the aircraft
Blinking blue The remote controller is linking to an aircraft
—— Solid yellow Firmware update failed
—— Solid blue Firmware update successful
Blinking yellow The battery level of the remote controller is low
Blinking cyan Control sticks not centered

dji Mini 3 Specifications

General

Type	Quadcopter
Foldable	Yes
Certification	FCC
Product color	Gray
Construction type	Ready-to-fly (RTF)
Maximum speed	10.55 m/s
Number of axis	3
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Number of rotors	4 rotors
Bluetooth version	5.2
Maximum tilt angle	40 °
Maximum ascent speed	5 m/s
Maximum descent speed	3.5 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10.7 m/s
Vertical hover accuracy	0.3 m
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum pitch angular velocity	250 °/sec
Megapixel	12 MP
Sensor type	CMOS
Digital zoom	4 x
Video resolutions	1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/1.3 \
Camera shutter speed	1/8000-2 s
Supported video modes	720p
Supported file systems	FAT32, exFAT
Angular vibration range	-0.01 - 0.01 °
Image formats supported	DNG, JPG
Maximum aperture number	1.7
Video formats supported	H.264
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	82.1 °
Bitrate at maximum video resolution	100 Mbit/s
Built-in processor	-
Compatible memory cards	MicroSD (TransFlash), MicroSDXC
Maximum memory card size	512 GB
Flight modes	Failsafe mode
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
USB ports quantity	1
Operating frequency	2400-24835, 5725-5850 MHz
Maximum device width	86 mm
Charging time	64 min
Operating time	38 min
Battery voltage	7.38 V
Battery capacity	2453 mAh
Transmitter battery capacity	5200 mAh
Cables included	Lightning, Micro-USB, USB, USB Type-C
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	362 mm
Width	251 mm
Height	72 mm
Weight	248 g
Battery weight	80.5 g
