dji Mini 3 User Manual

DJI Mini 3
User Manual
36
©
2022 DJI All Rights Reserved.
Battery Level LEDs
Blinking Pattern Battery Level
75%~100%
50%~75%
25%~50%
1%~25%
Remote Controller Alert
The remote controller beeps when there is an error or warning. Pay attention when prompts
appear on the touch screen or in DJI Fly. Slide down from the top and select Mute to disable all
alerts, or slide the volume bar to 0 to disable some alerts.
The remote controller sounds an alert during RTH. The RTH alert cannot be cancelled. The
remote controller sounds an alert when the battery level of the remote controller is low (6% to
10%). A low battery level alert can be cancelled by pressing the power button. The critical low
battery level alert, which is triggered when the battery level is less than 5%, cannot be cancelled.
Optimal Transmission Zone
The signal between the aircraft and the remote controller is most reliable when the remote
controller is positioned towards the aircraft as depicted below.
Optimal Transmission
•
DO NOT use other wireless devices operating at the same frequency as the remote
controller. Otherwise, the remote controller will experience interference.
•
A prompt will be displayed in DJI Fly if the transmission signal is weak during flight.
Adjust the remote controller orientation to make sure that the aircraft is in the optimal
transmission range.
Weak Signal

dji Mini 3 Specifications

General

Type	Quadcopter
Foldable	Yes
Certification	FCC
Product color	Gray
Construction type	Ready-to-fly (RTF)
Maximum speed	10.55 m/s
Number of axis	3
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Number of rotors	4 rotors
Bluetooth version	5.2
Maximum tilt angle	40 °
Maximum ascent speed	5 m/s
Maximum descent speed	3.5 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10.7 m/s
Vertical hover accuracy	0.3 m
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum pitch angular velocity	250 °/sec
Megapixel	12 MP
Sensor type	CMOS
Digital zoom	4 x
Video resolutions	1920 x 1080, 2720 x 1530, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/1.3 \
Camera shutter speed	1/8000-2 s
Supported video modes	720p
Supported file systems	FAT32, exFAT
Angular vibration range	-0.01 - 0.01 °
Image formats supported	DNG, JPG
Maximum aperture number	1.7
Video formats supported	H.264
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	82.1 °
Bitrate at maximum video resolution	100 Mbit/s
Built-in processor	-
Compatible memory cards	MicroSD (TransFlash), MicroSDXC
Maximum memory card size	512 GB
Flight modes	Failsafe mode
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
USB ports quantity	1
Operating frequency	2400-24835, 5725-5850 MHz
Maximum device width	86 mm
Charging time	64 min
Operating time	38 min
Battery voltage	7.38 V
Battery capacity	2453 mAh
Transmitter battery capacity	5200 mAh
Cables included	Lightning, Micro-USB, USB, USB Type-C
Operating temperature (T-T)	-10 - 40 °C

Weight and Dimensions

Depth	362 mm
Width	251 mm
Height	72 mm
Weight	248 g
Battery weight	80.5 g
