dji ZENMUSE X7 User Manual

©
2018 DJI All Rights Reserved.
11
ZENMUSE X7 User Manual
Lens
DL 24mm
F2.8 LS ASPH
DL 35mm
F2.8 LS ASPH
DL 50mm
F2.8 LS ASPH
DL-S 16mm
F2.8 ND ASPH
Focal Length 24 mm 35 mm 50 mm 16 mm
35 mm equivalent (stills) 37 mm 54 mm 77 mm 24 mm
Aperture Range F2.8~F16 F2.8~F16 F2.8~F16 F2.8~F16
FOV*
3:2 23.5×15.7 mm 52.2×36.2° 37.1×25.3° 26.5×17.9° 72.6×52.3°
17:9
23.5×12.5 mm 52.2×29.2° 37.1×20.3° 26.5×14.3° 72.6×42.7°
15.4×8.2 mm 35.6×19.4° 24.8×13.4° 17.5×9.4° 51.4×28.8°
16:9
22.5×12.7 mm 50.2×29.6° 35.6×20.6° 25.4×14.5° 70.2×43.3°
14.5×8.2 mm 33.6×19.4 ° 23.4×13.4° 16.5×9.4° 48.8×28.8°
2.44:1 23.5×9.6 mm 52.2×22.6° 37.1×15.6° 26.5×11.0° 72.6×33.4°
Close Focus 0.65 m 0.85 m 0.93 m 0.40 m
Filter Diameter 46 mm 46 mm 46 mm 46 mm
Elements/Groups/ASPH
elements
9 / 8 / 3 9 / 8 / 3 9 / 7 / 2 13 / 12 / 4
Barrel Dimensions
(diameter × length)
∅
55.0×71.2 mm
(including lens
hood)
∅
55.0×71.2 mm
(including lens
hood)
∅
55.0×71.2 mm
(including lens
hood)
∅
55.0×69.1 mm
(including lens
hood)
Weight Approx.178 g Approx.180 g Approx.182 g Approx.182 g
Lens Specifications
* This table only contains information of the sensor size eective for imaging and the corresponding FOVs in
dierent frame ratios.
Mounting Filters/Protector
1. Rotate the lens hood to remove it.
2. Rotate the balancing ring to remove it.
3. Mount the new lter (or the new protector) and the lens hood. When mounting the lens hood,
rst align the small red dot on the lens hood with the red dot on the lens, then rotate the lens
hood to align the big red dot with the dot on the lens.
1
3
22
4. If two lens lters are to be mounted to the lens. Please attach those lters to the lens and
DO NOT mount the lens hood back in step 3. But, the capability to reduce are may reduce
without the lens hood.
