2018 DJI All Rights Reserved.
19
ZENMUSE X7
User Manual
During an update, the aircraft will make a quick single beep continuously. The warning
sound will then alternate between a longer beep and a quick double beep once the
update is complete. Restart the aircraft after the rmware update is complete.
If the warning sound turns into a long beep, retry the update.
The battery level should be above 30% for the rmware update process.
When using the DJI GO 4 app to update, you may disconnect the aircraft and the mobile
device once the update is more than 30% completed. No Internet connection is required.
Specications
General
Product Name Zenmuse X7
Dimensions 151 × 108 × 132 mm
Weight (Lens Excluded) 449 g
Gimbal
Angular Vibration Range ±0.005°
Mount Detachable
Controllable Range Tilt: +40° to -125°; Pan: ±300°; Roll: ±20°
Mechanical Range Tilt: +50° to -130°; Pan: ±330°; Roll: +90° to -50°
Max Controllable Speed Tilt: 180°/s; Roll: 180°/s; Pan: 360°/s
Camera
Sensor
Sensor size (Still): 23.5×15.7mm
Sensor size (Max video recording area): 23.5×12.5mm
Eective Pixels: 24MP
Supported Lenses
DJI DL-S 16mm F2.8 ND ASPH
DJI DL 24mm F2.8 LS ASPH
DJI DL 35mm F2.8 LS ASPH
DJI DL 50mm F2.8 LS ASPH
Supported MicroSD/SSD
cards
MicroSD: Class 10 or UHS-1 rating with a writing speed of 15MB/s
required; Max capacity: 64 GB (some 128 GB MicroSD cards)
SSD: DJI CINESSD
Recommended MicroSD
Card
Sandisk Extreme 32GB UHS-3 MICROSDHC
Sandisk Extreme 64GB UHS-3 MICROSDXC
Panasonic 32GB UHS-3 MicroSDHC
Panasonic 64GB UHS-3 MicroSDXC
Samsung PRO 32GB UHS-3 MicroSDHC
Samsung PRO 64GB UHS-3 MicroSDXC
Samsung PRO 128GB UHS-3 MicroSDXC
Photo Size 3:2 4:3 16:9
