6
©
2018 DJI All Rights Reserved.
ZENMUSE X7
User Manual
DJI DL/DL-S Lens (Optional)
Lens Mounting Index
Lens Hood Mounting Index
Balancing Ring
Lens Hood
Getting Started
Read the information below before setting up your Zenmuse X7
Supported Devices
The Zenmuse X7 can be attached to the following device, and will be compatible with other DJI
devices in the future:
DJI Inspire 2 series
Supported Lenses for the Zenmuse X7
The Zenmuse X7 currently supports the following lenses, and will support additional lenses in the
future.
DJI DL-S 16mm F2.8 ND ASPH
DJI DL 24mm F2.8 LS ASPH
DJI DL 35mm F2.8 LS ASPH
DJI DL 50mm F2.8 LS ASPH
Example: DJI DL 24mm F2.8 LS ASPH Lens
For sharp and clear videos, the shutter speed should be no shorter than 1/500s when
using a focal length no longer than 35 mm; and a shutter speed no shorter than 1/600s
when using a focal length longer than 35 mm.
