DLab Digital - Display

10
Heating knob Heat
(Hotplate model)
Set the rated temperature in the safe
temperature range from room temperature
to 340 °C
. The function “heating” is
switched ON or OFF via the knob.
LED heat (Hotplate
model)
When the heating function is switched ON,
the LED Heat is lit.
LED Power
When the device is switched ON, the LED
power is lit.
Power switch Switch ON or OFF.
Table 2
4.2. Display(LCD digital model)
Figure 5
