16
The unit can be controlled from an external PC (using the dedicated software) via
the RS232C serial interface fitted to the unit. Data communication from laboratory
instrument to computer is only possible on demand of the computer.
The functions of the interface lines between laboratory instrument and
automation system are selected from the specified signals of the EIA-standard
RS232C, corresponding with DIN66020 Part 1. The allotment of the bushing
can be taken from Figure 7
Transmission method: Asynchronous signal transmission in start-stop-operation.
Mode of transmission: Fully Duplex. 1 start bit; 7-character bits; 1 parity bit
[straight (even)); 1 stop bit.
Transmission speed: 9600 bit/s
Start remote control knob LCD display “ Remote ”.
Note:
Forbid to insert or remove the RS232C communication line
when switch on!
